Delta ME300 Series - 05 Motor Parameters

Chapter 11 Summary of Parameter SettingsME300
11-20
05 Motor Parameters
Pr. Explanation Settings Default
05-00
Motor parameter auto-
tuning
0: No function
1: Dynamic test for induction motor (IM)
2: Static test for induction motor (IM)
13: High frequency stall test for PM
0
05-01
Full-load current for
induction motor 1 (A)
10–120% of the drive’s rated current
Depending
on the
model
power

05-02
Rated power for induction
motor 1 (kW)
0.00–655.35 kW
Depending
on the
model
power

05-03
Rated speed for induction
motor 1 (rpm)
0–xxxxx rpm (Depending on the motor’s number of poles)
1710 (60 Hz, 4 poles); 1410 (50 Hz, 4 poles)
Depending
on the
motor’s
number of
poles
05-04
Number of poles for
induction motor 1
2–20 4
05-05
No-load current for
induction motor 1 (A)
0.00–Pr.05-01 default
Depending
on the
model
power
05-06
Stator resistance (Rs) for
induction motor 1
0.000–65.535 Ω
Depending
on the
model
power
05-07
Rotor resistance (Rr) for
induction motor 1
0.000–65.535 Ω
0.000
05-08
Magnetizing inductance
(Lm) for induction motor 1
0.0–6553.5 mH 0.0
05-09
Stator inductance (Lx) for
induction motor 1
0.0–6553.5 mH 0.0
05-13
Full-load current for
induction motor 2 (A)
10–120% of the drive’s rated current
Depending
on the
model
power

05-14
Rated power for induction
motor 2 (kW)
0.00–655.35 kW
Depending
on the
model
power

05-15
Rated speed for induction
motor 2 (rpm)
0–xxxxx rpm
(Depending on the motor’s number of poles)
1710 (60 Hz, 4 poles); 1410 (50 Hz, 4 poles)
Depending
on the
motor’s
number of
poles
05-16
Number of poles for
induction motor 2
2–20 4
