Chapter 11 Summary of Parameter SettingsME300
11-25
Pr. Explanation Settings Default
31: EEPROM read error (cF2)
33: U-phase error (cd1)
34: V-phase error (cd2)
35: W-phase error (cd3)
36: cc hardware failure (Hd0)
37: oc hardware failure (Hd1)
40: Auto-tuning error (AUE)
41: PID loss ACI (AFE)
48: ACI loss (ACE)
49: External fault (EF)
50: Emergency stop (EF1)
51: External base block (bb)
52: Password is locked (Pcod)
54: Illegal command (CE1)
55: Illegal data address (CE2)
56: Illegal data value (CE3)
57: Data is written to read-only address (CE4)
58: Modbus transmission time-out (CE10)
63: Over-slip (oSL)
72: S1 internal loop detection error (STL1)
76: STO (STo)
77: S2 internal loop detection error (STL2)
78: S3 internal loop detection error (STL3)
82: Output phase loss U phase (OPL1)
83: Output phase loss V phase (OPL2)
84: Output phase loss W phase (OPL3)
87: Overload protection at low frequency (oL3)
142: Auto-tune error 1 (AUE1)
143: Auto-tune error 2 (AUE2)
149: Total resistance measurement fault (AUE5)
150: No-load current IO measurement fault (AUE6)
151: dq axis inductance measurement fault (AUE7)
152: High frequency injection measurement fault (AUE8)
157: Pump PID feedback error (dEv)
06-23 Fault output option 1 0–65535 (refer to bit table for fault code) 0
06-24 Fault output option 2 0–65535 (refer to bit table for fault code) 0
06-25 Fault output option 3 0–65535 (refer to bit table for fault code) 0
06-26 Fault output option 4 0–65535 (refer to bit table for fault code) 0
