Delta ME300 Series - 08 High-function PID Parameters

Chapter 11 Summary of Parameter SettingsME300
11-32
08 High-function PID Parameters
Pr. Explanation Settings Default

08-00
Terminal selection of
PID feedback
0: No function
1: Negative PID feedback: by analog input (Pr.03-00)
4: Positive PID feedback: by analog input (Pr.03-00)
7: Negative PID feedback:
by communication protocols
8: Positive PID feedback:
by communication protocols
0

08-01 Proportional gain (P)
0.0–1000.0 (When Pr.08-23 bit1 = 0)
0.00–100.00 (When Pr.08-23 bit1 = 1)
1.00

08-02 Integral time (I) 0.00–100.00 sec. 1.00

08-03 Differential time (D) 0.00–1.00 sec. 0.00

08-04
Upper limit of integral
control
0.0–100.0% 100.0

08-05
PID output command
limit (positive limit)
0.0–100.0% 100.0

08-06
PID feedback value by
communication protocol
-200.00–200.00% 0.00

08-07 PID delay time 0.0–2.5 sec. 0.0

08-08
Feedback signal
detection time
0.0–3600.0 sec. 0.0

08-09
Feedback signal fault
treatment
0: Warn and continue operation
1: Fault and ramp to stop
2: Fault and coast to stop
3: Warn and operate at last frequency
0

08-10 Sleep level 0.00–599.00 Hz 0.00

08-11 Wake-up level 0.00–599.00 Hz 0.00

08-12 Sleep delay time 0.0–6000.0 sec. 0.0

08-13
PID feedback signal error
deviation level
1.0–50.0% 10.0

08-14
PID feedback signal error
deviation time
0.1–300.0 sec. 5.0

08-15
PID feedback signal filter
time
0.1–300.0 sec. 5.0

08-16
PID compensation
selection
0: Parameter setting
1: Analog input
0

08-17 PID compensation -100.0–100.0% 0
08-18
Sleep mode function
setting
0: Refer to PID output command
1: Refer to PID feedback signal
0

08-19 Wake-up integral limit 0.0–200.0% 50.0
