Chapter 11 Summary of Parameter SettingsME300
11-34
Pr. Explanation Settings Default
08-65 PID target value source
0: Frequency command (Pr.00-20, Pr.00-30)
1: Pr.08-66 setting
2: RS-485 communication input
3: External analog input (refer to Pr.03-00)
4: CANopen communication card
6: Communication card
(does not include CANopen card)
7: Digital keypad potentiometer knob
0
08-66 PID target value setting -100.00–100.00% 50.00
08-67
Master and auxiliary
reveres running cutoff
frequency
0.0–100.0% 10.0
08-68 PID deviation limit 0.00–100.00% 0.00
08-69 Integral separation level 0.00–100.00% 0.00
08-70 Smart start-up level 0.00–100.00% 5.00
08-71
Smart start-up frequency
command
0.00–599.00 Hz 0.00
08-72
Smart start-up
acceleration time
0.00–600.00 sec. 3.00
08--75
PID2 parameter switch
condition
0: No switching (refer to Pr.08-01–Pr.08-03)
1: Auto-switch based on the output frequency
2: Auto-switch based on the deviation
0
08-76
PID2 parameter switch
deviation 1
0.00–Pr.08-77 setting (Unit: %) 10.00
08-77
PID2 parameter switch
deviation 2
Pr.08-76–100.00% 40.00
08-78
Allowed reverse running
time after start-up
0.0–6553.5 sec. 0.0
