Chapter 11 Summary of Parameter SettingsME300
11-35
09 Communication Parameters
Pr. Explanation Settings Default
09-00 Communication address 1–254 1
09-01
COM1 transmission
speed
4.8–38.4 Kbps 9.6
09-02
COM1 transmission fault
treatment
0: Warn and continue operation
1: Fault and ramp to stop
2: Fault and coast to stop
3: No warning, no fault, and continue operation
3
09-03 COM1 time-out detection 0.0–100.0 sec.
0.0
09-04
COM1 communication
protocol
1: 7, N, 2 (ASCII)
2: 7, E, 1 (ASCII)
3: 7, O, 1 (ASCII)
4: 7, E, 2 (ASCII)
5: 7, O, 2 (ASCII)
6: 8, N, 1 (ASCII)
7: 8, N, 2 (ASCII)
8: 8, E, 1 (ASCII)
9: 8, O, 1 (ASCII)
10: 8, E, 2 (ASCII)
11: 8, O, 2 (ASCII)
12: 8, N, 1 (RTU)
13: 8, N, 2 (RTU)
14: 8, E, 1 (RTU)
15: 8, O, 1 (RTU)
16: 8, E, 2 (RTU)
17: 8, O, 2 (RTU)
1
09-09
Communication response
delay time
0.0–200.0 ms 2.0
09-10
Communication main
frequency
0.00–599.00 Hz 60.00
09-11 Block transfer 1 0–65535 0
09-12 Block transfer 2 0–65535 0
09-13 Block transfer 3 0–65535 0
09-14 Block transfer 4 0–65535 0
09-15 Block transfer 5 0–65535 0
09-16 Block transfer 6 0–65535 0
09-17 Block transfer 7 0–65535 0
09-18 Block transfer 8 0–65535 0
09-19 Block transfer 9 0–65535 0
09-20 Block transfer 10 0–65535 0
