Chapter 12 Description of Parameter Settings
ME300
12.1-00-15
 If Pr.00-29 is not set to 0, the top right corner of digital keypad KPC-CC01 (optional) displays LOC
or REM. Set the REMOTE and LOCAL frequency and operation source with Pr.00-20, 00-21 and
Pr.00-30, 00-31. Set the multi-function input terminal (MI) = 56 to set the LOC / REM selection.
The AUTO key on the KPC-CC01 (optional) is the REMOTE function; the HAND key is the LOCAL
function.
 If Pr.00-29 is not set to 0, the AUTO / HAND keys are disabled. In this case, the external terminal
(MI) setting = 56 (local / remote selection) has the highest command priority.

00-30
Master Frequency Command Source (HAND, LOCAL)
Default: 0
Settings
0: Digital keypad
1: RS-485 communication input
2: External analog input (Refer to Pr.03-00)
3: External UP / DOWN terminal (multi-function input terminals)
7: Digital keypad potentiometer knob
9: PID controller
Note:
HOA (Hand-Off-Auto
) function is valid only when you use with MO function
setting 41 and 56 or with KPC-CC01 (optional).
 Determines the master frequency source in the "HAND, LOCAL" mode.
 You can switch the HAND, LOCAL mode with the keypad KPC-CC01 (optional) or the multi-
function input terminal (MI) to set the master frequency source.
 It returns to AUTO or REMOTE mode whenever you cycle the power. If you use a multi-function
input terminal to switch between HAND (LOCAL) and AUTO (REMOTE) mode, the highest priority
is the multi-function input terminal.
 The pulse of Pr.00-20 = 4 (Pulse input without direction command) is input by PG or MI5.

00-31
Operation Command Source (HAND, LOCAL)
Default: 0
Settings 0: Digital keypad
1: External terminals
2: RS-485 communication input
 Determines the operation frequency source in the "HAND, LOCAL" mode.
 In the HOA mode, if the multi-function input terminal (MI) function setting 41 and 42 are OFF, the
drive does not receive any operation command and JOG is invalid.

00-32
Digital Keypad STOP Function
Default: 0
Settings 0: STOP key disable
1: STOP key enable
 This parameter is valid when the digital keypad is not set as the operation source (Pr.00-21 ≠ 0).
When Pr.00-21 = 0, the STOP key on the digital keypad is not affected by this parameter.
