Analog input level
reached output
The multi-function output terminals operate when the
level is between the high level and the low level.
Pr.03-44: Select one of the analog input channels (AVI, ACI)
to be compared.
Pr.03-45: The high level for the analog input, default is 50%.
Pr.03-46: The low level for the analog input, default is 10%.
If analog input > Pr.03-45, the multi-function output terminal
operates.
If analog input < 03-46, the multi-function output terminal
stops output.
69 Indication of Preheating
Active when preheating function is enabled.
75 Forward RUN status
When the drive runs FWD, the output terminal status for forward
running is closed; when the drive stops, the output terminal
status for forward running is open.
76 Reverse RUN status
When the drive runs REV, the output terminal status for reverse
running is closed; when the drive stops, the output terminal
status for reverse running is open.
77
Program Running
Indication
Closed when running program auto-run.
78
Program Step
Completed Indication
Closed for only 0.5 second whenever completing one step during
program auto-run.
79
Program Running
Completed Indication
Closed for only 0.5 seconds when the program auto-run
completes all steps.
80
Program Running
Paused Indication
Closed when the action of auto-run terminals are paused
externally during program auto-run.
81
Multi-pump system error
display (only Master)
Closed when errors occur on all drives for the multi-
Multi-function Output Direction
Default: 0000h
Settings 0000h–FFFFh (0:N.O.; 1:N.C.)
This parameter is in hexadecimal.
This parameter is set by a bit. If the bit is 1, the corresponding multi-function output acts in an
opposite way.
Example:
Assume Pr.02-13 = 1 (indication when the drive is operating). If the output is positive, the bit is
set to 0, and then Relay is ON when the drive runs and is OFF when the drive stops. On the
contrary, if the output is negative, and the bit is set to 1, then the Relay is OFF when the drive
runs and is ON when the drive stops.
bit 3 bit 2 bit 1 bit 0
MO1
reserved
reserved
RY
