Chapter 12 Description of Parameter SettingsME300
12.1-03-16

03-28
AI Terminal Input Selection
Default: 0
Settings 0: 0–10 V (Pr.03-63–03-68 is valid)
1: 0–20 mA (Pr.03-57–03-62 is valid)
2: 4–20 mA (Pr.03-57–03-62 is valid)
 Switch between voltage mode and current mode must work with manual switch. Refer to Chapter
06 for more information on AVI terminals.
 When you change the setting, proportion to the corresponding AI will change to default.

03-32
AFM DC Output Setting Level
Default: 0.00
Settings 0.00–100.00%

03-35
AFM Output Filter Time
Default: 0.01
Settings 0.00–20.00 sec.

03-39
VR Input Selection
Default: 1
Settings
0: Disable
1: Frequency command
 VR is the abbreviation for Variable Resistor; it is the potentiometer of the keyboard panel.

03-40
VR Input Bias
Default: 0.0
Settings -100.0–100.0%

03-41
VR Positive / Negative Bias
Default: 0
Settings
0: No bias
1: Lower than or equal to bias
2: Greater than or equal to bias
3: The absolute value of the bias voltage while serving as the center
4: Bias serves as the center

03-42
VR Gain
Default: 100.0
Settings -500.0–500.0%

03-43
VR Filter Time
Default: 0.01
Settings 0.00–2.00 sec.

03-44
Multi-function MO Output by AI Level Source
Default: 0
Settings 0: AVI
1: ACI
