Chapter 12 Description of Parameter Settings
ME300
12.1-06-22
06-90
Operation Time of Fault Record 5 (Day)
06-92
Operation Time of Fault Record 6 (Day)
Default: Read only
Settings 0–65535 days
06-64
Operation Time of Fault Record 1 (Min.)
06-66
Operation Time of Fault Record 2 (Min.)
06-68
Operation Time of Fault Record 3 (Min.)
06-70
Operation Time of Fault Record 4 (Min.)
06-91
Operation Time of Fault Record 5 (Min.)
06-93
Operation Time of Fault Record 6 (Min.)
Default: Read only
Settings 0–1439 min.
 If there is any malfunction when the drive operates, Pr.06-17–06-22 records the malfunctions, and
Pr.06-63–06-70 records the operation time for four sequential malfunctions. Check if there is any
problem with the drive according to the interval of the recorded fault.
Example:
The first error: ocA occurs after motor drive operates for 1000 minutes.
The second error: ocd occurs after another 1000 minutes.
The third error: ocn occurs after another 1000 minutes.
The fourth error: ocA occurs after another 1000 minutes.
The fifth error: ocd occurs after another 1000 minutes.
The sixth error: ocn occurs after another 1000 minutes.
Then Pr.06-17–06-22 and Pr.06-63–06-70 are recorded as follows:
1
st
fault 2
nd
fault 3
rd
fault 4
th
fault 5
th
fault 6
th
fault
Pr.06-17
ocA ocd ocn ocA ocd
ocn
Pr.06-18
0 ocA ocd ocn ocA ocd
Pr.06-19
0 0 ocA ocd ocn
ocA
Pr.06-20 0 0 0 ocA ocd ocn
Pr.06-21 0 0 0 0 ocA ocd
Pr.06-22
0 0 0 0 0 ocA
Pr.06-63
1000 560 120 1120 680
240
Pr.06-64
0 1 2 2 3
4
Pr.06-65
0 1000 560 120 1120
680
Pr.06-66 0 0 1 2 2 3
Pr.06-67 0 0 1000 560 120 1120
Pr.06-68
0 0 0 1 2 2
Pr.06-69
0 0 0 1000 560
120
Pr.06-70
0 0 0 0 1
2
NOTE: By examining the time record, you can see that that the last fault (Pr.06-17) happened
after the drive ran for 4 days and 240 minutes.
