Chapter 12 Description of Parameter Settings
ME300
12.1-09-9
Modbus address R/W Function
0011B: 3
rd
Step speed frequency
0100B: 4
th
Step speed frequency
0101B: 5
th
Step speed frequency
0110B: 6
th
Step speed frequency
0111B: 7
th
Step speed frequency
1000B: 8
th
Step speed frequency
1001B: 9
th
Step speed frequency
1010B: 10
th
Step speed frequency
1011B: 11
th
Step speed frequency
1100B: 12
th
Step speed frequency
1101B: 13
th
Step speed frequency
1110B: 14
th
Step speed frequency
1111B: 15
th
Step speed frequency
bit 12
1: Enable bit 06
–
11 function
bit 14–13
00B: No function
01B: Operated by digital keypad
10B: Operated by Pr.00-21 setting
11B: Change operation source
bit 15 Reserved
2001H RW Frequency command (XXX.XX Hz)
2002H RW
bit 0 1: EF (external fault) on
bit 1 1: Reset
bit 2 1: B.B. ON
bit 15–3 Reserved
Status monitor read only (21xx)
Modbus address R/W Function
2100H R
High byte: Warn code
Low Byte: Error code
2101H R
bit 1–0
AC motor drive operation status
00B: Drive stops
01B: Drive decelerating
10B: Drive standby
11B: Drive operating
bit 2 1: JOG command
bit 4–3
Operation direction
00B: FWD run
01B: From REV run to FWD run
10B: REV run
11B: From FWD run to REV run
2101H R bit 8 1: Master frequency controlled by communication
