Chapter 12 Description of Parameter Settings
ME300
12.1-13-6
Pr. Parameter Name Settings
03-12 Analog input gain (ACI) 100.0%
03-50 Analog input curve selection 1: Three-point curve of AVI
03-63 AVI voltage lowest point 0.00
03-65 AVI voltage mid-point 9.99
03-66 AVI proportional mid-point 100%
08-00 Terminal selection of PID feedback
1: Negative PID feedback: by
analog input (Pr.03-00, Pr.03-01)
08-01 Proportional gain (P) 10
08-02 Integral time (I) 1.00 (sec.)
08-20 PID mode selection 1: Parallel connection
08-21 Enable PID to change the operation direction
0: Operation direction cannot be
changed
08-65 PID target value source 1: Pr.08-66 setting
08-66 PID target value setting 50.00%
08-67
Master and auxiliary reverse running cutoff
frequency
10.0%

13-00
–
13-50
Application Parameters (User-Defined)
