Chapter 5 Main Circuit TerminalsME300
5-7
Frame B
Figure 5-9
 If you install at Ta 50°C above environment, use copper wires that have a
voltage rating of 600V and
are temperature resistant to 90°C or above.
 If you install at Ta 50°C environment, use copper wires that have a voltage rating of 600V and
are
temperature resistant to 75°C or 90°C.
 To be UL installation compliant, you must use copper wires when installing.
The wire gauge is based
on a temperature resistance of 75°C, in accordance with UL requirements and recommendations.
Do not reduce the wire gauge when using high-temperature resistant wires.
Table 5-4
Models
Main Circuit Terminals
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3,
DC-, DC+/+1, +2/B1, B2
Terminals
Max. Wire
Gauge
Min. Wire
Gauge
Screw &
Torque
(±10%)
Max. Wire
Gauge
Min. Wire
Gauge
Screw &
Torque
(±10%)
VFD0A8ME21AFNAA
4 mm
2
[12 AWG]
0.75mm
2
[18AWG]
M4
15 Kg-cm
[13.0 lb-in.]
[1.47 Nm]
2.5mm
2
[14 AWG]
2.5mm
2
[14 AWG]
M4
15 Kg-cm
[13.0 lb-in.]
[1.47 Nm]
VFD0A8ME21AFSAA
VFD1A6ME21AFNAA
1.5mm
2
[16AWG]
VFD1A6ME21AFSAA
VFD2A8ME21AFNAA
2.5mm
2
[14 AWG]"
VFD2A8ME21AFSAA
VFD4A8ME21ANNAA
4 mm
2
[12 AWG]
4 mm
2
[12 AWG]
4 mm
2
[12 AWG]
VFD4A8ME21AFNAA
VFD4A8ME21ANSAA
VFD4A8ME21AFSAA
VFD7A5ME23ANNAA
VFD7A5ME23ANSAA
VFD1A5ME43AFNAA
0.75mm
2
[18AWG]
2.5mm
2
[14 AWG]
2.5mm
2
[14 AWG]
VFD1A5ME43AFSAA
VFD2A7ME43AFNAA
VFD2A7ME43AFSAA
VFD4A2ME43ANNAA
2.5mm
2
[14 AWG]
VFD4A2ME43AFNAA
VFD4A2ME43ANSAA
VFD4A2ME43AFSAA
