Chapter 7 Optional AccessoriesME300
7-15
230V, 50–60 Hz / Three-Phase - Normal Duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Intput /
Output AC
Reactor
(mH)
Intput AC
reactor
Delta part #
Outtput AC
reactor
Delta part #
DC
Reactor
(mH)
DC reactor
Delta part #
VFD0A8ME23ANNAA
VFD0A8ME23ANSAA
1 1.5 2.536
DR005A0254 DR005L0254 5.857 DR005D0585
VFD1A6ME23ANNAA
VFD1A6ME23ANSAA
1.8 2.7 2.536
DR005A0254 DR005L0254 5.857 DR005D0585
VFD2A8ME23ANNAA
VFD2A8ME23ANSAA
3.2 4.8 2.536
DR005A0254 DR005L0254 5.857 DR005D0585
VFD4A8ME23ANNAA
VFD4A8ME23ANSAA
5 7.5 2.536
DR005A0254 DR005L0254 5.857 DR005D0585
VFD7A5ME23ANNAA
VFD7A5ME23ANSAA
8 12 1.585
DR008A0159 DR008L0159 3.66 DR008D0366
VFD11AME23ANNAA
VFD11AME23ANSAA
12.5 18.75 0.746
DR017AP746 DR017LP746 2.662 DR011D0266
VFD17AME23ANNAA
VFD17AME23ANSAA
19.5 29.25 0.507
DR025AP507 DR025LP507 1.722 DR017D0172
VFD25AME23ANNAA
VFD25AME23ANSAA
27 40.5 0.32
DR033AP320 DR033LP320 1.172 DR025D0117
Table 7-14
230V, 50–60 Hz / Three-Phase - Heavy Duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Intput /
Output AC
Reactor
(mH)
Intput AC
reactor
Delta part #
Outtput AC
reactor
Delta part #
DC
Reactor
(mH)
DC reactor
Delta part #
VFD0A8ME23ANNAA
VFD0A8ME23ANSAA
0.8 1.6 2.536
DR005A0254 DR005L0254 5.857 DR005D0585
VFD1A6ME23ANNAA
VFD1A6ME23ANSAA
1.6 3.2 2.536
DR005A0254 DR005L0254 5.857 DR005D0585
VFD2A8ME23ANNAA
VFD2A8ME23ANSAA
2.8 5.6 2.536
DR005A0254 DR005L0254 5.857 DR005D0585
VFD4A8ME23ANNAA
VFD4A8ME23ANSAA
4.8 9.6 2.536
DR005A0254 DR005L0254 5.857 DR005D0585
VFD7A5ME23ANNAA
VFD7A5ME23ANSAA
7.5 15 1.585
DR008A0159 DR008L0159 3.66 DR008D0366
VFD11AME23ANNAA
VFD11AME23ANSAA
11 22 1.152 DR011A0115 DR011L0115 2.662
DR011D0266
VFD17AME23ANNAA
VFD17AME23ANSAA
17 34 0.746
DR017AP746 DR017LP746 1.722 DR017D0172
VFD25AME23ANNAA
VFD25AME23ANSAA
25 50 0.507
DR025AP507 DR025LP507 1.172 DR025D0117
Table 7-15
460V, 50–60 Hz / Three-Phase - Normal Duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Intput /
Output AC
Reactor
(mH)
Intput AC
reactor
Delta part #
Outtput AC
reactor
Delta part #
DC
Reactor
(mH)
DC reactor
Delta part #
VFD1A5ME43ANNAA
VFD1A5ME43AFNAA
VFD1A5ME43ANSAA
VFD1A5ME43AFSAA
1.8 2.7 8.102 DR003A0810 DR003L0810 18.709 DR003D1870
