Chapter 7 Optional AccessoriesME300
7-14
230V, 50–60 Hz / One-Phase - Normal Duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Intput AC / DC
Reactor
(mH)
Intput AC / DC
reactor
Delta part #
Output AC
reactor
(mH)
Output AC
reactor
Delta part #
VFD0A8ME21ANNAA
VFD0A8ME21AFNAA
VFD0A8ME21ANSAA
VFD0A8ME21AFSAA
1 1.5 5.857 DR005D0585 2.54 DR005L0254
VFD1A6ME21ANNAA
VFD1A6ME21AFNAA
VFD1A6ME21ANSAA
VFD1A6ME21AFSAA
1.8 2.7 5.857 DR005D0585 2.54 DR005L0254
VFD2A8ME21ANNAA
VFD2A8ME21AFNAA
VFD2A8ME21ANSAA
VFD2A8ME21AFSAA
3.2 4.8 3.66 DR008D0366 2.54 DR005L0254
VFD4A8ME21ANNAA
VFD4A8ME21AFNAA
VFD4A8ME21ANSAA
VFD4A8ME21AFSAA
5 7.5 2.66 DR011D0266 2.54 DR005L0254
VFD7A5ME21ANNAA
VFD7A5ME21AFNAA
VFD7A5ME21ANSAA
VFD7A5ME21AFSAA
8.5 12.75 1.72 DR017D0172 1.15 DR011L0115
VFD11AME21ANNAA
VFD11AME21AFNAA
VFD11AME21ANSAA
VFD11AME21AFSAA
12.5 18.75 1.17 DR025D0117 0.746 DR017LP746
Table 7-12
230V, 50–60 Hz / One-Phase - Heavy Duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Intput AC / DC
Reactor
(mH)
Intput AC / DC
reactor
Delta part #
Output AC
reactor
(mH)
Output AC
reactor
Delta part #
VFD0A8ME21ANNAA
VFD0A8ME21AFNAA
VFD0A8ME21ANSAA
VFD0A8ME21AFSAA
0.8 1.6 5.857 DR005D0585 2.54 DR005L0254
VFD1A6ME21ANNAA
VFD1A6ME21AFNAA
VFD1A6ME21ANSAA
VFD1A6ME21AFSAA
1.6 3.2 5.857 DR005D0585 2.54 DR005L0254
VFD2A8ME21ANNAA
VFD2A8ME21AFNAA
VFD2A8ME21ANSAA
VFD2A8ME21AFSAA
2.8 5.6 3.66 DR008D0366 2.54 DR005L0254
VFD4A8ME21ANNAA
VFD4A8ME21AFNAA
VFD4A8ME21ANSAA
VFD4A8ME21AFSAA
4.8 9.6 2.66 DR011D0266 2.54 DR005L0254
VFD7A5ME21ANNAA
VFD7A5ME21AFNAA
VFD7A5ME21ANSAA
VFD7A5ME21AFSAA
7.5 15 1.72 DR017D0172 1.59 DR008L0159
VFD11AME21ANNAA
VFD11AME21AFNAA
VFD11AME21ANSAA
VFD11AME21AFSAA
11 22 1.17 DR025D0117 1.15 DR011L0115
Table 7-13
