Denon AVR-1311 User Manual

32
ENGLISH
Examples of front display
Below we describe typical examples of displays on the set’s display window.
Front Display Description
Top menu display
Speaker Setup
w
q
q The number of the current selected setting menu is displayed.
w The currently selected item is displayed on the display.
Use ui to move to the item you want to set.
Display when changing settings
Front •Large–
w
e
q
Speaker Config.
w
q
r Press ENTER.
t Press RETURN.
Speaker Setup
w
q
q The number of the current selected setting menu is displayed.
w Use ui to move to the item you want to set.
e • – is displayed at the sides of item whose setting can be changed. Use o p to change to the desired setting.
r Press ENTER to set to the mode in which the setting can be made.
t Press RETURN to return to the previous menu.
Display when resetting
Default? :• No
q
w
q
Default
Press ENTER.
q The number of the current selected setting menu is displayed.
w Press
i to select “Default”, then press ENTER to set.
1.AVR1311E2ENG3rd100617.inddSec:321.AVR1311E2ENG3rd100617.inddSec:32 2010/06/1718:24:202010/06/1718:24:20

Denon AVR-1311 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
3D Technology	Yes
HDMI Pass-Through	Yes
Frequency Response	10 Hz - 100 kHz
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, THD 0.08%)
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS-HD Master Audio
Tuner Type	FM/AM
Speaker Impedance	6 - 16 ohms
Weight	8.3 kg
