Denon AVR-1311 - Rear Panel

42
ENGLISH
Rear panel
See the page indicated in parentheses ( ).
q t
wer
yuioQ0Q1
q PRE OUT connectors ··························································· (5, 28)
w Speaker terminals ······························································· (5, 28)
e DOCK CONTROL jack ······························································ (16)
r S-VIDEO connector ································································· (16)
t COMPONENT VIDEO connectors ····································· (13, 14)
y AC inlet (AC IN) ·········································································· (5)
u VIDEO connectors ····························································· (13, 14)
i HDMI connectors ····································································· (12)
o Digital audio connectors ··················································· (13, 14)
Q0 Analog audio connectors ·················································· (14, 16)
Q1 FM/AM antenna terminals ····················································· (16)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
