Denon AVR-1312 Service Manual

100
Ref. No. Part No. Part Name Remarks Q'ty New
C958-963 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C964 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C965 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C966 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C967-969 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C970 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C971,972 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C973,974 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C975 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
OTHERS PARTS GROUP
BD61-63 nsp CHIP FERRITE BEAD(60ohm 2012) CLZ9R001Z
BD71,72 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
BD81 nsp CHIP FERRITE BEAD(60ohm 2012) CLZ9R001Z
BD83 nsp CHIP,BEAD HLZ9Z008Z
BD91-95 nsp CHIP FERRITE BEAD(60ohm 2012) CLZ9R001Z
BK61 nsp PCB BRACKET CMD1A569
BN12 nsp WIRE ASS'Y (5P, 100MM) CWB1C005100G7
CN1A nsp WAFER FPC 23P 1.25mm CJP23GA285ZN
CN42,43 nsp
LOCKING TYPE, STRAIGHT WAFER
2MM
CJP15GI236ZW
CN71 nsp LOCKINGTYPE STRAIGHTWAFER 2MM CJP03GI236ZW
CN8A nsp WAFER CARD CABLE 23P, 1.0MM CJP23GA193ZY
CN91 nsp WAFER CARD CABLE 7P 1.25MM CJP07GB113ZY
CN9A nsp WAFER CARD CABLE 13P 1.25MM CJP13GA115ZY
ET71 nsp EARTH PALTE HJT1A025
ET91 nsp EARTH PALTE HJT1A025
JK62 943643010170S JACK NOSPCC6PWWW/RRR CJJ4R019T
JK71 943643010180S JACK NOSPCC2PY/Y CJJ4N092U
JK72 943643010190S JACK NOSPCCRCA/SVIDEO CJJ9N004U
JK81 943643010210S JACK ASS'Y CJS9U017Z+HJSTORX177L HJSTORX177L
JK82 943643100030S JACK RCA CJJ4M044X *
JK91 943643010220S JACK 3.5PIHORIZONTALWITHOUTRING CJJ2E033Z
L601,602 943115010270S MPX COIL(FM19KHzFILTER) CLM4B001Z
TU61 943183010320S
TUNER(USA)FM(SCREW:FTYPE)
,AM(S/LAB)
E3 CNVMW004MV1S63SN
TU61 943183010310S TUNER(EUR)FM,AM,RDS(S/LAB) E2,E1C,EA CNVMW104MV1S63N
X801 943141010360S CRYSTAL 24.576MHz 15PF 30PPM HOX24576E150TF
X901 943141010370S CRYSTAL 10.000MHz 22PF 30PPM HOX10000E220TF

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
