Denon AVR-1312 Service Manual

93
MAIN P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC41 00D2630641002 REGULATOR IC NJM7912FA HVINJM7912FA
IC42 00D2630801004 REGULATOR IC NJM7812FA HVINJM7812FA
IC45 00D2631162014 REGULATOR IC KIA78R05PI HVIKIA78R05PI
IC46 231010031706S REGULATOR IC KIA278R05PI HVIKIA278R05PI
Q401 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q402,403 00D9430154200 TR KRA102M HVTKRA102MT
Q408 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q410-414 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q415 00D2710301903 TR KTA1268BLATP CVTKTA1268BLATPA
Q416 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q417-420 943216500030S TR KRC105M CVTKRC105MT *
Q421-423 00D2710301903 TR KTA1268BLATP CVTKTA1268BLATPA
Q424 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q425-428 00D2710301903 TR KTA1268BLATP CVTKTA1268BLATPA
Q429-436 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q437-444 00D2710301903 TR KTA1268BLATP CVTKTA1268BLATPA
Q445 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q448-453 00D9430108104 TR KTC2874B HVTKTC2874BT
Q454 00MHT30001000 TR KTC3199Y HVTKTC3199YT
Q455 00D9430004305 TR KRC107M HVTKRC107MT
Q456 00MHT30001000 TR KTC3199Y HVTKTC3199YT
Q457,458 00D2710301903 TR KTA1268BLATP CVTKTA1268BLATPA
Q459,460 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q461-463 90M-HT800120R TR KTC3114A HVTKTC3114A
Q464 90M-HT400490R POWER TR 2SD2390 HVT2SD2390
Q465 90M-HT800120R TR KTC3114A HVTKTC3114A
Q466 90M-HT200440R POWER TR HVT2SB1560 HVT2SB1560
Q467 90M-HT400490R POWER TR 2SD2390 HVT2SD2390
Q468 90M-HT200440R POWER TR HVT2SB1560 HVT2SB1560
Q469 90M-HT400490R POWER TR 2SD2390 HVT2SD2390
Q470 90M-HT200440R POWER TR HVT2SB1560 HVT2SB1560
Q471 90M-HT400490R POWER TR 2SD2390 HVT2SD2390
Q472 90M-HT200440R POWER TR HVT2SB1560 HVT2SB1560
Q473 90M-HT400490R POWER TR 2SD2390 HVT2SD2390
Q474 90M-HT200440R POWER TR HVT2SB1560 HVT2SB1560
Q475 90M-HT800120R TR KTC3114A HVTKTC3114A
D401 943202010050S DIODE ZJ2.4B CVDZJ2.4BT
D402 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D404 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D409-437 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D438,439 943203003150S DIODE 1N4007T HVD1N4007T
D445,446 90M-HD201850R SCHOTTKY DIODE 1N5819 HVD1N5819T
D448 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D449-454 943203003150S DIODE 1N4007T HVD1N4007T
D455 nsp COPPER WIRE C3A206
D458-460 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D461 943203003170S DIODE GBJ606 HVDGBJ606
D501 nsp COPPER WIRE C3A206
ZD41 943202008160S DIODE ZJ12B CVDZJ12BT
ZD48 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD49 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD51-60 90M-HD302390R DIODE ZJ3.3B CVDZJ3.3BT
RESISTORS GROUP
R494-501 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) FLAMERETARDANT CRG1SANJ4R7RT *
R502 nsp RES,M-OXIDEFILM(1W/120ohm) CRG1SANJ121RT
R505-514 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT *
R515 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R516-520 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT *
R527-531 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
