Denon AVR-1312 Service Manual

108
SYS-1312 PARTS LIST OF PACKING VIEW
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. and Canada model E2 : Europe model
Ref. No. Part No. Part Name Remarks Q'ty New
1 nsp MIRROR MAT 715-140031-00 5 *
2 nsp UNWOVEN CLOTH 442-9A3W04-00 5 *
3 nsp POLYFORM 720-S1312B-00 1 *
4 nsp POLYFORM 720-S1312T-00 1 *
5 nsp PE BAG 700-220001-00 1 *
6 nsp EPE BAG 710-140037-00 1 *
7 nsp POLYFORM 720-W1312B-00 1 *
8 nsp POLYFORM 720-W1312T-00 1 *
9 nsp CORK 441-902N01-00 1 *
10 nsp CORD 319-131201-10 1 *
11 nsp CONTROL LABEL 605-W13120-00 1 *
12 nsp PE BAG 700-120006-00 1 *

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
