Denon AVR-1312 Service Manual

29
SURROUND MODES AND PARAMETERS
Symbols in the table
S This indicates the audio output channels or surround parameters that can be set. D This indicates the audio output channels. The output channels depend on the settings of “Speaker Config.”.
Surround mode)
Channel output Audio Adjust
Front L/R Center Surround L/R Surround Back L/R Subwoofer Mode
D. Comp z3 DRC z4 LFE z5
DIRECT (2channel)
S D
z2
S S
DIRECT (Multi-channel)
S D D D
z1
D S S S
STEREO
S D S S S
MULTI CH IN
S D D D D S
DOLBY PRO LOGIC gx S D D D D S S S DOLBY PRO LOGIC g S D D D S S S
DTS NEO:6
S D D D D S S S
DOLBY DIGITAL
S D D D D S S
DOLBY DIGITAL Plus
S D D D D S S
DOLBY TrueHD
S D D D D S
DTS SURROUND
S D D D D S S
DTS 96/24
S D D D D S S
DTS-HD
S D D D D S S
DTS Express
S D D D D S S
MULTI CH STEREO
S D D D D S S
VIRTUAL
S D
z2
S S
z1 A signal for each channel contained in an input signal is output as audio. z2 Only when “SW Mode” is set to “LFE+Main” (“Bass Setting”), sound is output from the subwoofer. z3 This item can be selected when a Dolby Digital or DTS signal is played. z4 This item can be selected when a Dolby TrueHD signal is played. z5 This item can be selected when a Dolby Digital or DTS signal or DVD-Audio is played.

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
