Denon AVR-1312 Service Manual

90
PARTS LIST OF P.W.B. UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model EA : Australia model
BK : Black model SP : Premium Silver model
FRONT P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC602,603 943239005300M IC BA4560RF HVIBA4560RF
Q6001 943219006820S TR KTC1027Y CVTKTC1027YT
Q6002 943216500020S TR RT1N141C CVTRT1N141C *
Q6003,6004 943214500020S TR 2SC3052 CVT2SC3052 *
Q6005 00MHT600141B1 TR KTA1271Y HVTKTA1271YT
Q6006 943216500020S TR RT1N141C CVTRT1N141C *
Q6007 943215500020S TR RT1P141C CVTRT1P141C *
Q6009 943215500020S TR RT1P141C CVTRT1P141C *
Q6010 943216500020S TR RT1N141C CVTRT1N141C *
Q6011 943215500020S TR RT1P141C CVTRT1P141C *
Q6012 943216500020S TR RT1N141C CVTRT1N141C *
D213 943203003170S DIODE GBJ606 HVDGBJ606
D216-219 943203003150S DIODE 1N4007T HVD1N4007T
D6001,6002 943203003150S DIODE 1N4007T HVD1N4007T
D6003 90M-HD302360R DIODE ZJ6.8BT CVDZJ6.8BT
D6004 00D9430087209 ZENER DIODE ZJ24B 1/2W CVDZJ24BT
D6005 90M-HD302450R ZENER DIODE ZJ13B 1/2W CVDZJ13BT
D6014 943176010090S LED BLBJEGJ204L CVDBLBJEGJ204L
D6015,6016 943209001080S DIODE 1SS355T E1C CVD1SS355T
D6017-6020 943209001080S DIODE 1SS355T CVD1SS355T
RESISTORS GROUP
z
R268,269 943125500020S METAL RES FILM, 0.22ohm 1W 5% CRG1SANJR22RTP *
z
R275,276 943125500020S METAL RES FILM, 0.22ohm 1W 5% CRG1SANJR22RTP *
z
R283,284 943125500020S METAL RES FILM, 0.22ohm 1W 5% CRG1SANJR22RTP *
z
R285,286 943125500020S METAL RES FILM, 0.22ohm 1W 5% CRG1SANJR22RTP *
R6008 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R6062 nsp CHIP RES1%75OHM CRJ10DF75R0T
R6090,6091 nsp RES,M-OXIDEFILM(2W/470ohm) CRG2SANJ471RT
VR601 943671010330S ENCODER VR CSR2A055Z
CAPACITORS GROUP
C244 nsp METALLIZED CAP 0.1UF 250V J KCME2E104JP04T
C246,247 nsp METALLIZED CAP 0.1UF 250V J KCME2E104JP04T
C248-250 nsp METALLIZEDFILM CAP 0.047UF 100V CCME2A473JXT
C255-257 nsp METALLIZEDFILM CAP 0.047UF 100V CCME2A473JXT
C6002 nsp MYLAR CAP 0.1UF 50V J HCQI1H104JZT
C6003 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6004 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6005 00MOA22706320 ELECT CAP 220UF 63V CCEA1JH221E
C6006 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6007 nsp METALLIZEDFILM CAP 0.047UF 100V CCME2A473JXT
C6009 nsp CHIP CAP 0.1UF/50V/2012 CCUC1H104KC
C6010 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6011 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6013-6015 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6016 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C6017 nsp METALLIZEDFILM CAP 0.047UF 100V CCME2A473JXT
C6019 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
