Denon AVR-1312 Service Manual

91
Ref. No. Part No. Part Name Remarks Q'ty New
C6020 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C6035 943134010670S ELECT CAP 47UF 16V CCEA1CKS470T
C6036 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6038 943134010530S ELECT CAP 1UF 50V C E1C CCEA1HH1R0T
C6039,6040 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6041 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6042,6043 nsp CHIP CAP 220PF 50V CCUS1H221JA
C6049 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6050 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6059,6060 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6062 nsp CHIP CAP 0.1UF 50V K E1C CCUS1H104KC
C6063-6065 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6067 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6069,6070 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C6071 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6072-6076 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6077,6078 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C6081,6082 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6089 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6090 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6091 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6092-6094 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6095 nsp CHIP CAP 220PF 50V E3,E2,EA CCUS1H221JA
C6095 nsp CHIP CAP 100PF 50V J E1C CCUS1H101JA
C6096 nsp CHIP CAP 220PF 50V E3,E2,EA CCUS1H221JA
C6096 nsp CHIP CAP 100PF 50V J E1C CCUS1H101JA
C6100,6101 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
OTHERS PARTS GROUP
BK601,602 nsp FIP BRACKET CMD1A572
BN45 nsp WIRE ASSY(LOCK 3P 120MM 2.5MM) CWB1D00312058
BN46 nsp WIRE ASS'Y (7P, 250MM) CWB4D00725058
BN606 nsp WIRE ASS'Y (3P, 300MM) CWB4B00330047
BN61A nsp WIREASS'Y (5P, 50MM) CWB1B00505047
BN61B nsp WIREASS'Y (5P, 80MM) CWB1B005080E7
BN63A nsp WIREASS'Y (5P, 100MM ) CWB1B00510067
BN64A nsp WIREASS'Y (3P, 80MM) CWB1B00308077
BN71-74 nsp WIREASS'Y (1P, 40MM) CWE7202040TT
CN201 nsp WAFER STRAIGHT(7PIN 2.5MM) CJP07GA01ZY
CN203 nsp WAFER(3PIN 3.96MM) CJP03GA148ZW
CN41 nsp WAFER STRAIGHT(3PIN 3.96MM) CJP03GA90ZY
CN602 nsp WAFER,FPC 23P 1.25mm angle CJP23GB286ZN
CN603 nsp LOCKINGTYPE STRAIGHTWAFER 2MM CJP03GI236ZW
CN610 nsp WAFER ANGLE(2.5mm) CJP05GB03ZY
CN61A nsp LOCKINGTYPE STRAIGHTWAFER 2mm CJP05GI236ZW
CN61B nsp WAFER STRAIGHT CJP05GA19ZY
z
F6001 943652000620S FUSE(0.1A 372SERIES/TR5) CBA2D0100A3EYT
FL601 943172012630S V.F.D 18-ST-15GINK CFL18ST15GINK *
GND21 nsp PCB BRACKET CMD1A569
GND22 nsp PCB BRACKET CMD1A188
JK602 90M-YT004310R JACK BOARD(3P) CJJ4S041Z
JK603 943643010140S JACK HEADPHONE(3.5mm GOLD) CJJ2E028Z
JK605 943643010130S JACK PHONES(6.35mm) CJJ2E020Z
L6001,6002 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
L6006-6008 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
LUG65,67 nsp WIRE ASS'Y 1P, 100MM CWE8102100RV

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
