Denon AVR-1312 Service Manual

102
Ref. No. Part No. Part Name Remarks Q'ty New
OTHERS PARTS GROUP
BK11,12 nsp PCB BRACKET CMD1A569
CN11 nsp WAFER 7P 1.25MM CJP07GA117ZY
CN12 nsp WAFER SMD(2MMPITCH) CJP05GA208ZY
CN8B nsp WAFER CARDCABLE(23P, 1MM) CJP23GA193ZY
JK11-15 943643100040S JACK,HDMI(KSI-TWI,W/FLANGE) CJJ9H014Z *
L101-108 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
L109 nsp CHIP FERRITE BEAD(60ohm 4516) CLZ9Z014Z
L114 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
X101 943141010350S CRYSTAL 28.636MHz 33PF 30PPM COX28636E330S

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
