Denon AVR-1312 Service Manual

95
Ref. No. Part No. Part Name Remarks Q'ty New
C441,442 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C443-445 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C446-449 00D9430148708 ELECT CAP 47UF 50V CCEA1HH470T
C450-456 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C457 943134010480S ELECT CAP 100UF 100V CCEA2AH101E
C458,459 nsp CERAMIC CAP 0.01UF 50V ZF CCFT1H103ZF
C460 943134010610S ELECT CAP 4.7UF 50V CCEA1HH4R7T
C461 943134010610S ELECT CAP 4.7UF 50V CCEA1HH4R7T
C462 943134010580S ELECT CAP 220UF 35V CCEA1VH221T
C463 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C464 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C465 nsp CERAMIC CAP 330PF 50V KB CCKT1H331KB
C466 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C467,468 nsp CERAMIC CAP 330PF 50V KB CCKT1H331KB
C469-471 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
z
C472 943132500020S CERAMIC CAP (400V Y-CAP) CCKDHS222ME *
C474 00D9430103905 ELECT CAP470UF 16V CCEA1CH471T
C475,476 943134010460S ELECT CAP 6800UF 63V (30X35) CCET63VKL5682NKZ
C477 943134010620S ELECT CAP 4700UF 25V CCEA1EH472E
C480 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C481-483 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C484 nsp CERAMIC CAP 0.022UF 50V ZF CCFT1H223ZF
C486 943134001290S ELECT CAP 2200UF 25V CCEA1EH222E
C487 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C488 nsp CERAMIC CAP 0.01UF 50V ZF CCFT1H103ZF
C489 943134010600S ELECT CAP 3300UF 16V CCEA1CH332E
C490 nsp CERAMIC CAP 0.01UF 50V ZF CCFT1H103ZF
C491 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C492 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C493 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C494 nsp MYLAR CAP 2200PF 100V J HCQI1H222JZT
C495 nsp CERAMIC CAP 100PF 50V KB CCKT1H101KB
C495 nsp CERAMIC CAP 82PF 50V J E2,E1C,EA CCCT1H820JC
C496 943134010580S ELECT CAP 220UF 35V CCEA1VH221T
C497 nsp CERAMIC CAP 33PF 50V J CCCT1H330JC
C498,499 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C500 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C502 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C504 943134010600S ELECT CAP 3300UF 16V CCEA1CH332E
C505 00D9430148708 ELECT CAP 47UF 50V CCEA1HH470T
C508 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C559 943134010470S ELECT CAP 0.1UF 50V CCEA1HH0R1T
C561 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C563,564 943134010470S ELECT CAP 0.1UF 50V CCEA1HH0R1T
OTHERS PARTS GROUP
BK41 nsp PCB BRACKET CMD1A569
BN41 nsp WIRE ASS'Y (3P, 200MM) CWB3FE03200UZ
BN42 nsp WIREASS'Y (15P, 100MM) CWB1B01510047
BN43 nsp WIRE ASS'Y (15P, 200MM) CWB4C01520047
BN44 nsp WIREASS'Y (3P, 250MM) CWB4B00325047
BN45 nsp WIRE ASS'Y (1P, 200MM) CWE8202200VV
BN9B nsp WAFER CARD CABLE, 13PIN 1.25MM CJP13GA115ZY
CN45 nsp STRAIGHT WAFER 3PIN 2.5MM CJP03GI237ZW
CN46 nsp STRAIGHT WAFER 7PIN 2.5MM CJP07GI237ZW
CN47 nsp WAFER 2PIN 2MM CJP02KA060ZY
CN48 nsp WAFER 2PIN CJP02GA89ZY
CN51-55 nsp WAFER STRAIGHT 2PIN CJP02GA01ZY
ET41 nsp EARTH PALTE HJT1A025
z
F401 90M-FS001420R FUSE(218Series 250V 3.15A) E2,EA,E1C KBA2C3150TLEY
z
F401 90M-FS001430R FUSE(218Series 250V 6.3A) E3 KBA2C6300TLEY

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
