Denon AVR-1312 Service Manual

98
Ref. No. Part No. Part Name Remarks Q'ty New
C642,643 00D9430148708 ELECT CAP 47UF 50V CCEA1HH470T
C647 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C651 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C652-655 nsp CHIP CAP 1500PF 50VK CCUS1H152KC
C656,657 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C658,659 nsp CHIP CAP 1500PF 50VK CCUS1H152KC
C660 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C661,662 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C663,664 943134010610S ELECT CAP 4.7UF 50V CCEA1HH4R7T
C665 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C668-670 nsp CHIP CAP 1500PF 50VK CCUS1H152KC
C671 nsp CHIP CAP 4700PF 50V CCUS1H472KC
C672 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C673 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C674 nsp CHIP CAP 1500PF 50VK CCUS1H152KC
C675 nsp CHIP CAP 4700PF 50V CCUS1H472KC
C676 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C677 nsp CHIP CAP 3900PF 50V K CCUS1H392KC
C678 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C679 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C680,681 943134010610S ELECT CAP 4.7UF 50V CCEA1HH4R7T
C682 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C685-688 nsp CHIP CAP 1500PF 50VK CCUS1H152KC
C689,690 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C691,692 nsp CHIP CAP 1500PF 50VK CCUS1H152KC
C693 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C694,695 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C696,697 943134010610S ELECT CAP 4.7UF 50V CCEA1HH4R7T
C698 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C701-704 nsp CHIP CAP 1500PF 50VK CCUS1H152KC
C705,706 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C707,708 nsp CHIP CAP 1500PF 50VK CCUS1H152KC
C709 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C710,711 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C712,713 943134010610S ELECT CAP 4.7UF 50V CCEA1HH4R7T
C714 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C718 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C720 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C724-726 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C727 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C728 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C729 nsp CHIP CAP 0.22UF 16VK CCUS1C224KC
C730 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C731 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C732 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C733 nsp CHIP CAP 220PF 50V CCUS1H221JA
C735 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C736 nsp CHIP CAP 2700PF 50V K CCUS1H272KC
C737 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C738 nsp CHIP CAP 220PF 50V CCUS1H221JA
C740 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C741 nsp CHIP CAP 2700PF 50V K CCUS1H272KC
C742 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C743 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C745 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C747 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C752 nsp RES,CHIP(0OHM,5%,1608) CRJ10DJ0R0T
C754,755 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C756-C758 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C759 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C763-765 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C766 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C768 00D9430148708 ELECT CAP 47UF 50V CCEA1HH470T
C769 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C770 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C771 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C772 nsp CHIP CAP 22PF 50V CCUS1H220JA

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
