Denon AVR-1507 Operating Instructions

ENGLISH
45
ENGLISH
Operating the remote control unit Operating the remote control unit
Operating a component stored in the preset
memory
Operate the component.
For details, refer to the component’s operating instructions.
Some models cannot be operated with this remote control unit.
Set [MODE SELECTOR 1] to “AUDIO” or “VIDEO”.
Set to the AUDIO side for the CD, TAPE or CD-R/MD position, and
to the VIDEO side for the DVD/VDP, DBS/CABLE, VCR or TV
position.
1
3
Set [MODE SELECTOR 2] to the component you want
to operate.
2
[MODE SELECTOR 1]
[OFF]
[SHIFT]
[SETUP]
, [DISPLAY],
[ENTER]
, [D H F G],
[AUDIO]
, [RETURN] ,
[MENU]
[ 2 ] , [ 1 ] , [ 3 ],
[
6 7 ],
[VCR CH + –]
,
[ 8 9 ] ,
[ 0 ], [DISC SKIP +]
[MODE SELECTOR 2]
[ON/SOURCE]
[CHANNEL + –]
[TUNING + – ] ,
[TV VOL. + – ] ,
[ MODE/MENU ] ,
[ BAND/PICTURE ADJUST ] ,
[MEMORY/SUBTITLE]
[NUMBER] ( 0 ~ 9, +10)
[TV/VCR]
[SETUP] ,
[ AUDIO ] ,
[ENTER] ,
[D H
F G],
[DISPLAY]
,
[ RETURN ]
[POWER]

Denon AVR-1507 Specifications

General

Digital Inputs	2 Optical, 1 Coaxial
Analog Inputs	5
Tuner	AM/FM
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Sensitivity	200 mV
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
Input Impedance	47 kOhm
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
DSP Presets	5-channel stereo, Cinema EQ
