Specifications
n Audio section
• Power amplifier
Rated output: Front:
75 W + 75 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
110 W + 110 W (6 Ω, 1 kHz with 0.7 % T.H.D.)
Center:
75 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
110 W (6 Ω, 1 kHz with 0.7 % T.H.D.)
Surround:
75 W + 75 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
110 W + 110 W (6 Ω, 1 kHz with 0.7 % T.H.D.)
Surround back:
75 W + 75 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
110 W + 110 W (6 Ω, 1 kHz with 0.7 % T.H.D.)
Output connectors: 6 – 16 Ω
• Analog
Input sensitivity/Input impedance: 200 mV/47 kΩ
Frequency response: 10 Hz – 100 kHz — +1, –3 dB (DIRECT mode)
S/N: 98 dB (IHF–A weighted, DIRECT mode)
n Video section
• Standard video connectors
Input/output level and impedance: 1 Vp-p, 75 Ω
Frequency response: 5 Hz – 10 MHz — +1, –3 dB
n Tuner section [FM] [AM]
(Note: μV at 75 Ω, 0 dBf = 1 x 10
–15
W)
Receiving Range: 87.5 MHz – 107.9 MHz 520 kHz – 1710 kHz
Usable Sensitivity: 1.2 μV (12.8 dBf) 18 μV
50 dB Quieting Sensitivity: MONO 2.8 μV (20.2 dBf)
S/N (IHF-A): MONO 70 dB
STEREO 67 dB
Total harmonic Distortion (at 1 kHz): MONO 0.7 %
STEREO 1.0 %
n General
Power supply: AC 120 V, 60 Hz
Power consumption: 450 W
0.1 W (Standby)
3 W (CEC standby)
Maximum external dimensions: 434 (W) x 171 (H) x 381 (D) mm (17-3/32” x 6-47/64” x 15”)
Weight: 9.2 kg (20 lbs 4.5 oz)
n Remote Control Unit (RC-1146)
Batteries: R6/AA Type (two batteries)
Maximum external dimensions: 53 (W) x 224 (H) x 28 (D) mm (2-3/32” x 8-13/16” x 1-7/64”)
Weight: 160 g (Approx 5.6 oz, including batteries)
For purposes of improvement, specifications and design are subject to change without notice.
Index
v Numerics
2.1-channel ························································· 30
2ch DIRECT/STEREO ········································· 52
3D ······································································· 14
5.1-channel ··························································· 4
6.1-channel ··················································· 28, 29
7.1-channel ··················································· 28, 29
v A
Accessories ·························································· 1
Adjust CH ··························································· 47
Adobe RGB color / Adobe YCC601 color ··········· 69
AFDM ································································· 44
Amp Assign ························································ 49
ARC ···································································· 15
Audio Adjust ······················································· 43
Audio cable ··············································· 5, 16, 17
Audio Delay ························································ 48
Audio Setup ························································ 52
Audyssey Auto Setup ····································· 6, 31
Audyssey Dynamic EQ ································· 46, 69
Audyssey Dynamic Volume ························· 47, 69
Audyssey MultEQ ·································· 46, 61, 69
Audyssey Settings ············································· 46
Auto Lip Sync ··············································· 51, 69
Auto Preset ························································ 40
Auto Setup ····················································· 6, 31
Auto Surround Mode ·········································· 52
v B
banana plug ·························································· 4
Base Curve Copy ················································ 47
Bass ··································································· 45
Bass Setting ······················································· 50
Bi-amp ································································ 30
Browse mode ····················································· 21
v C
Cable
Audio cable ·············································5, 16, 17
Coaxial digital cable ········································· 17
Component video cable ··································· 17
HDMI cable ·················································· 5, 15
Optical cable ···················································· 16
Speaker cable ···················································· 5
Video cable ·················································16, 17
Center Image ····················································· 44
Center Width ······················································ 44
Channel Level ····················································· 50
Characters ·························································· 38
Cinema EQ ························································· 44
Coaxial digital cable ············································ 17
Component video cable ····································· 17
Condensation ······················································· 2
Connection
Antenna ··························································· 18
Blu-ray Disc player ····································· 15, 16
Cable TV ··························································· 17
Control dock for iPod ········································ 18
Digital camcorder ············································· 17
DVD player ················································· 15, 16
External control device ···································· 19
Game console ·················································· 15
HDMI ······························································· 14
Power cord ························································· 5
Satellite tuner ··················································· 17
Set-top box ·················································15, 17
Speaker ························································ 4, 29
TV··························································· 5, 15, 16
Crossover Frequency ········································· 50
v D
D.Comp ······························································ 44
Decode Mode ···················································· 42
Deep Color ··················································· 14, 69
DENON original surround mode ························· 26
Dimension ·························································· 44
Display ·························································· 54, 61
Distance ····························································· 50
Dolby
Dolby Digital··············································· 25, 69
Dolby Digital EX ········································· 25, 69
Dolby Digital Plus ······································· 25, 69
Dolby Pro Logic II ············································· 69
Dolby Pro Logic IIx ··········································· 69
Dolby Pro Logic IIz ·····································28, 69
Dolby TrueHD ············································· 25, 69
Downmix ···························································· 69
DRC ···································································· 44
DTS ······························································ 25, 69
DTS 96/24 ·················································· 25, 69
DTS-ES Discrete 6.1 ·································· 25, 69
DTS-ES Matrix 6.1 ····································· 25, 69
DTS-HD ······················································ 25, 69
DTS-HD High Resolution Audio ······················· 69
DTS-HD Master Audio ····································· 69
DTS Digital Surround ······································· 69
DTS Express ···················································· 69
DTS NEO:6™ Surround ····························· 24, 70
Dynamic EQ ······················································· 46
Dynamic range ··················································· 70
Dynamic Volume ················································ 47
