Getting Started Connections Playback Remote Control Multi-Zone Information Troubleshooting
ENGLISH
0
~
3
~
6
Dimension
Shift sound image center to front or rear, to adjust playback balance.
[Variable range]
0
~
3
~
7
0 ms
~
30 ms
~
300 ms
1
~
10
~
15
Small
Medium small
Medium
Medium large
Large
Delay Time
Adjust delay time to control sound stage size.
Effect
Switch effect signal for multi-surround speakers on and off.
Effect Level
Adjust effect signal level.
Room Size
Determine size of acoustic environment.
Center Width
Assign center channel signal to front left and right channels for wider
sound.
[Variable range]
[Variable range]
[Variable range]
[Selectable items]
ON
OFF[Selectable items]
Set to a lower level if the positioning and sense of phase of the
surround signals seems unnatural.
NOTE
“Room Sizedoes not indicate the size of the room in which sources
are played.
NON MTRX
MTRX ON
PL
II
x CINEMA
z1
PL
II
x MUSIC
z2
ES MTRX
z3
ES DSCRT
z4
DSCRT ON
OFF
z1: This can be selected when “Surround Back” is set to “2spkrs”
at the GUI menu “Manual Setup” – “Speaker Setup” – “Speaker
Configuration” setting (vpage 29).
z2: This can be selected when “Surround Back” is set to “2spkrs”
or “1spkr” at the GUI menu “Manual Setup” “Speaker Setup”
–“Speaker Configuration” setting.
z3: This can be selected when playing DTS sources.
z4: This can be selected when playing DTS sources including a
discrete 6.1-channel signal identification signal.
ON
OFF
[Selectable items]
AFDM
Auto-select surround mode by source.
This function only works for software containing a special identification
signal.
If the software being played is recorded in Dolby Digital EX or DTS-ES,
it is played in 6.1-channels. If not, it is played in 5.1-channels.
Example : Playing Dolby Digital software (with EX flag)
When AFDM” is set to ON”, the surround mode is automatically
set to the DOLBY D + PLgx C mode.
To play in the DOLBY DIGITAL EX mode, set “AFDM” to “OFF” and
“SB CH Out” to “MTRX ON”.
Some Dolby Digital EX sources do not include EX flags. If the playback
mode does not switch automatically even when AFDM” is set to
ON”, set “SB CH Out” to “MTRX ON” or “PLgx CINEMA.
SB CH Out (for Multi-channel sources)
Select playback mode for surround back channels.
[Selectable items]
ON
OFF
[Selectable items]
SB CH Out (for 2-channel sources)
Determine whether to use surround back speakers.
–10dB
~
0dB
0.0
~
0.3
~
1.0
Cinema EQ
Soften the treble range of movie soundtracks for better
understanding.
D.COMP
Compress dynamic range (difference between loud and soft sounds).
LFE
Adjust the low-frequency effects level (LFE).
Center Image
Assign center channel signal to front left and right channels for wider
sound.
Panorama
Assign front L/R signal also to surround channels, for wider sound.
[Selectable items]
[Variable range]
[Variable range]
[Selectable items]
[Selectable items]
ON
OFF
ON
OFF
OFF
Low
Middle
High
When playing DTS sources, this is only displayed for compatible
software.
For proper playback of the different program sources, we recommend
setting to the values below.
Dolby Digital sources: “0 dB”
DTS movie sources: “0 dB”
DTS music sources: “–10 dB”
DRC
Compress dynamic range (difference between loud and soft sounds).
[Selectable items]
Auto
Low
Middle
High
OFF
This can be set in the Dolby TrueHD mode.
Setup
1.AVR4308E2_ENG_3.indd 45 2007/10/26 11:42:28
