Video Camera / Game Console
Video camera / Game console
Component with Multi-channel Output
connectors
DVD player /
Super Audio CD player / External decoder
• To play the analog input signals input to the EXT. IN connectors,
press the INPUT MODE button on the main unit or INPUT button
on the main remote control unit and select “EXT. IN” or make the
settings at GUI menu “Source Select” – “(input source)” – “Input
Mode” – “Input Mode” – “EXT. IN” (vpage 40).
• The video signal can be connected in the same way as a DVD player
(vpage 13).
• To play copyright-protected discs, connect the AVR-4308’s EXT.
IN connector with the DVD player’s analog multi-channel output
connector.
46#
800'&3
$&/5&3 463306/%
#"$,
3-
463306/%
3-
'30/5
3-
"6%*0
R
L
R
L
R
L
R
L
R
L
R
L
External Power Amplifier
When using just one surround back speaker, connect it to the left
channel (SBL).
Power amplifier
Connections
1.AVR4308E2_ENG_3.indd 18 2007/10/26 11:41:27
