Denon AVR-X1100W Service Manual

1. Version Display Mode
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
Hold down buttons "
DIMMER
" and "
STATUS
" at the same time and press the power button to turn on the power.
Press the "
STATUS
" button after this to show the information in section 1.3 on the display.
b
A version list is also displayed on GUIs while the version appears on the display.
1.3. Display Order
Error information(See
1.4. Error display
) →
q
Model destination information →
w
Firmware Package Version
→
e
Main μ-com →
r
Main 1st Boot Loader →
t
DSP ROM →
y
Audio PLD →
u
GUI SFLASH
→
i
Ethernet 1st Boot Loader, Hardware ID →
o
Ethernet 2nd Boot Loader, Rhapsody Flag →
Q0
Ethernet IMAGE →
Q1
Ethernet MAC ADDRESS information →
Q2
BT MAC Address information
q
Model destination information :
FLD
A V R - S 7 0 0 W E 3 *
FLD
A V R - X 1 1 0 0 W E 3 *
FLD
A V R - X 1 1 0 0 W E 2 *
FLD
A V R - X 1 1 0 0 W E 1 *
FLD
A V R - X 1 1 0 0 W E 1 C *
FLD
A V R - X 1 1 0 0 W J P *
w
Firmware Package Version :
FLD
P a c k a g e : * * * *
e
Main µ-com Version :
FLD
M a i n : * * * * # # # # *
*
：
Main version,
#
：
Sub version
r
Main 1st Boot Loader :
FLD
M a i n F B L : * * . * *
t
DSP ROM :
FLD
D S P : * * . * *
y
Audio PLD :
FLD
A u d i o P L D : * * . * *
u
GUI SFLASH :
FLD
G U I : @ @ $ \ * * * *
@
：
Model code,
$
：
Brand code,
\
：
Region code,
*
：
version
18

Denon AVR-X1100W Specifications

General

Receiver type	Surround
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
Supported radio bands	AM, FM
Optical drive included	No
Display	VFL
Product color	Black
Audio decoders	Dolby Digital 5.1, Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Plus, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8600 g
