Denon AVR-X1100W Service Manual

Check the connection environment
YES
YES
YES
YES
Are the network settings of this unit correct?
Are peripheral devices such as the router and hub connected
correctly?
Are the router settings correct?
Set the IP address, etc. correctly.
If the IP settings are xed, check that no
other devices have the same IP address and
that the subnet mask settings are correct.
Connect the peripheral devices correctly.
Check the instruction manual of the router
and congure the settings correctly.
Check that there are no connection
restrictions by MAC addresses, etc.
NO
NO
NO
5. Network/Bluetooth/USB
5.1. Cannot connect to the network
YES
Is the LAN cable correctly inserted?
Insert the LAN cable correctly and then turn
on the power again.
NO
Check the connection environment
The circuit around CX870 is faulty.
Checking the unit
YES
YES
YES
YES
Can an output voltage (3.3V) to IC741 be conrmed?
Can an output voltage (1.2V) to IC743 be conrmed?
Are the versions of the Ethernet SBL and IMG displayed in Version
Check Mode?
Can a voltage (5V) be conrmed between pin 1 and pin 5 of CN741?
The circuit around IC741 or the circuit of the
3.3V devices is faulty.
The circuit around IC743 or CX870 is faulty.
The Ethernet software is faulty.
Check the SMPS PCB.
NO
NO
NO
NO
81

Denon AVR-X1100W Specifications

General

Receiver type	Surround
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
Supported radio bands	AM, FM
Optical drive included	No
Display	VFL
Product color	Black
Audio decoders	Dolby Digital 5.1, Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Plus, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8600 g
