Denon AVR-X1100W Service Manual

YES
YES
YES
NO
NO
NO
NO
NO
NO
YES
YES
No picture or sound is output.
Check the Blu-ray/DVD player.
Check the connection of the HDMI/DVI cable.
(1) Is the HDMI/DVI cable correctly inserted?
(3) Is a certied HDMI cable (with the HDMI mark) being used?
(4) Is the HDMI/DVI cable shorter than 5m?
(5) Are a picture and sound output when a different HDMI/DVI cable is
used?
(2) Is an HDMI/DVI selector, repeater or image quality improvement
device being used?
(6) Are the HDMI output settings of the Blu-ray/DVD player correct?
(8) Are a picture and sound output
when the resolution of the Blu-
ray/DVD player is changed?
(10) Are a picture and sound
output when a different Blu-
ray/DVD player is used?
(7) If using a DENON Blu-ray/DVD player, is the "HDMI" indicator of
the uorescent display lit?
Proceed to YES if using a Blu-ray/DVD player from another
company.
(9) Is sound output from the speaker terminal of this unit when the
power of the TV is turned off or the cable connecting the TV to this
unit is removed?
Check the connection of the HDMI/DVI
cable.
Use a certied HDMI cable (with the HDMI
mark).
Replace the HDMI/DVI cable with one
shorter than 5m (2m is recommended) and
check again.
The HDMI/DVI cable is faulty.
Remove all of these and connect only the
HDMI/DVI cable.
Check the instruction manual of the Blu-
ray/DVD player and set the HDMI output
correctly.
Set the output resolution of the Blu-ray/DVD
player to a resolution supported by the TV.
The Blu-ray/DVD player is faulty.
The Blu-ray/DVD player may not support the
HDCP repeater function.
Check with the manufacturer of the Blu-ray/
DVD player.
NO
NO
NO
YES
NO
YES
YES
YES
YES
3. HDMI/DVI
3.1. No picture or sound is output (HDMI to HDMI)
76

Denon AVR-X1100W Specifications

General

Receiver type	Surround
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
Supported radio bands	AM, FM
Optical drive included	No
Display	VFL
Product color	Black
Audio decoders	Dolby Digital 5.1, Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Plus, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8600 g
