Denon AVR-X1100W Service Manual

3. Selection Modes for Service-related Operations
3.1. Actions
Select diagnostic mode (service path check mode), protection history display mode, or 232C standby clear mode.
3.2. Starting up
AVR-X1100W
Hold down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" at the same time and press the power button to turn on
the power.
AVR-S700W
Hold down buttons "
TUNER PRESET CH+
", "
TUNE -
" and
TUNE +
" at the same time and press the power button to turn
on the power.
Select the mode using the button "
TUNER PRESET CH+
", and press the button "
STATUS
" to commit the selection.
3.3. Displaying and Selecting Each Mode
The information shown on the display changes each time the button "
TUNER PRESET CH+
" is pressed.
Press the button "
STATUS
" to set the currently displayed mode and restart the device.
q
FLD
1 . S E R V I C E C H E C K
Service Path Check Mode:
The Video and Audio paths can be checked.
This function is convenient for conrming problem paths in the product and executing a path
check after repair.
w
FLD
2 . P R O T E C T I O N
The protection history can be checked.
e
FLD
4 . O P I N F O
Operation Info for the unit can be checked.
r
FLD
5 . T U N E R F R Q S E T
Enables reception STEP of the ANALOG TUNER to be changed.
t
FLD
6 . R E M O T E I D
Function to operate only the desired AV receiver.
3.3. Canceling the mode
Press the power button to turn off the power.
23

Denon AVR-X1100W Specifications

General

Receiver type	Surround
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
Supported radio bands	AM, FM
Optical drive included	No
Display	VFL
Product color	Black
Audio decoders	Dolby Digital 5.1, Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Plus, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8600 g
