Denon AVR-X1100W Service Manual

5. Protection Pass Mode
5.1. Actions
• This mode allows the power to be turned on without activating protections.
• This is the same as normal power-on, except that protections are not activated.
5.2. Operations
AVR-X1100W
・
Hold down buttons "
TUNER PRESET CH +
", "
ZONE2 SOURCE
" and "
STATUS
" at the same time and press the power
button to turn on the power.
AVR-S700W
・
Hold down buttons "
ZONE2 SOURCE
", "
TUNER PRESET CH +
" and "
TUNE +
" at the same time and press the power
button to turn on the power.
The device returns to the normal display after the following is displayed.
FLD
P r o t e c t i o n P a s s
This is displayed for 5 seconds before returning to the normal display.
6. CX870 / CY920 Reboot mode
6.1. Actions
• The CX870 / CY920 is restarted after CX870 / CY920 hangup.
• The CX870 / CY920 can be restarted even in the network standby setting ("
Setup menu
" – "
Network
" – "
Network
" –
"
Always On
").
6.2. Operations
1. Turn on the button "
MAIN ZONE
" and set NETWORK as the input source.
2. Hold down buttons "
TUNER PRESET CH +
" and "
TUNER PRESET CH -
" for at least 3 seconds while the power is on.
3. FL display during CX870 / CY920 reboot
FLD
N e t w o r k R e s t a r t
4. Returns to the normal display.
NOTE:
• The CX870 / CY920 Reboot operation is not accepted again for one minute after executing the reboot.
• Reception is prohibited during update, save and load.
50

Denon AVR-X1100W Specifications

General

Receiver type	Surround
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
Supported radio bands	AM, FM
Optical drive included	No
Display	VFL
Product color	Black
Audio decoders	Dolby Digital 5.1, Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Plus, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8600 g
