Denon AVR-X1100W Service Manual

3.4.6. Audio system conrmation items
g. XX: See the block diagram of the g.XXth.
Paths conrmation item Display Settings Contents of conrmation Remarks
1
Analog ( pass )
A 0 1 : A N A L O G P A S S
Input Source: CBL/SAT
Input Mode: ANALOG xed
Sound mode: DIRECT
Amp assign: Surround Back
MAIN ZONE: ON
ZONE2: OFF
・
Check the audio output.
・
Check of Analog input
⇒
Speaker output.
Front L/R
（※
The input source can be switched to any source except CBL/SAT.
）
2
DIGITAL
(MAIN)
A 0 2 : D I G I T A L
Input Source : CBL/SAT
Input Mode : DIGITAL xed
Sound mode: MULTI CH STEREO
Amp assign : Surround Back
Speaker Cong all Speaker=Small / SW=Yes(2ch)
MAIN ZONE ON
ZONE2 OFF
・
Check the audio output.
・
Check of Digital input
⇒
Speaker output.
Front L/R
、
Center
、
Surround L/R
、
Surround Back L/R
・
Check of Digital(PCM) input
⇒
Preout output.
Front L/R
、
Center
、
Surround L/R
、
Surround Back L/R
、
Subwoofer
（※
The input source can be switched to any source except CBL/SAT.
）
3
HDMI
A 0 5 : H D M I
Input Source : CBL/SAT
Input Mode : HDMI xed
Sound mode: STEREO
Amp assign : Surround Back
MAIN ZONE: ON
ZONE2: OFF
・
Check the audio output.
・
HDMI input
⇒
Speaker output.
Front L/R
（※
The input source can be switched to any source except CBL/SAT.
）
4
Analog AD
(MAIN)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog xed
Sound mode: MULTI CH STEREO
Vol -20dB
Amp assign : Surround Back
Speaker Cong all Speaker=Small / SW=Yes(2ch)
MAIN ZONE: ON
ZONE2: OFF
・
Check the audio output.
・
Check of Analog input
⇒
Speaker output.
Front L/R
、
Center
、
Surround L/R
、
Surround Back L/R
・
Check of Analog input
⇒
Pre OUT.
Front L/R
、
Center
、
Surround L/R
、
Surround Back L/R
、
Subwoofer
（※
The input source can be switched to any source except CBL/SAT.
）
（※
Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used
）
5
Analog Amp Assign
(Amp Assign: ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: STEREO
Z2 Source : Source
Vol -20dB
Amp assign : ZONE2
MAIN ZONE: ON
ZONE2: ON
・
Check the audio output.
・
Check of Analog input
⇒
Speaker output.
Surround Back(ZONE2) L/R
・
Check of Analog input
⇒
Pre OUT.
ZONE2 L/R
（※
The input source can be switched to any source except CBL/SAT.
）
（※
Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used
）
6
Analog Amp Assign
(Amp Assign: Bi-Amp)
AVR-X1100W Only
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : Bi-Amp
MAIN ZONE ON
ZONE2 OFF
・
Check the audio output.
・
Check of Analog input
⇒
Speaker output.
Surround Back L/R
（※
The input source can be switched to any source except CBL/SAT.
）
（※
Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used
）
7
Front Height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Vol -20dB
Amp assign : Front Height
MAIN ZONE ON
ZONE2 OFF
・
Check the audio output.
・
Check of Analog input
⇒
Speaker output.
Surround Back L/R
（※
The input source can be switched to any source except CBL/SAT.
）
・
Check of PREOUT output.
（※
Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used
）
g.07
g.08a
g.08b
g.09a
g.09b
g.10a
g.10b
g.11
g.12
g.13a
g.13b
26

Denon AVR-X1100W Specifications

General

Receiver type	Surround
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
Supported radio bands	AM, FM
Optical drive included	No
Display	VFL
Product color	Black
Audio decoders	Dolby Digital 5.1, Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Plus, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8600 g
