Denon AVR-X1100W Service Manual

Error
Code
Details of Error code Display Coping strategies
86
Mismatched CheckSum in Check-
Sum comparison after rewriting.
U p d a t i n g f a i l 8 6
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
A2 Unable to detect USB.
C o n n e c t i o n F a i l A 2
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
A3 No FirmwareFile in USB.
F i l e s N o t F o u n d A 3
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
A4
FirmwareFile in USB for unsup-
ported Model name/area.
N o t M a t c h F i r m A 4
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
A6
Error notication received while
requesting FirmwareInfo.
U p d a t i n g f a i l A 6
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
A7
TimeOut while obtaining Firm-
ware information.
U p d a t i n g f a i l A 7
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
AE
Unable to detect USB for Firm-
wareDownload.
C o n n e c t i o n F a i l A E
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
AF
No FirmwareFile for Firmware-
Download.
F i l e s N o t F o u n d A F
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
B1
TimeOut in Download (writing to
SDRAM) for FirmwareDownload.
D o w n l o a d f a i l B 1
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
B2
Error notication received after
rewriting CX870 Firm.
U p d a t i n g f a i l B 2
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
B3
Error in FirmwareUpdate (Time-
Out).
U p d a t i n g f a i l B 3
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
B4
Failed to transit to BootLoader-
Mode.
U p d a t i n g f a i l B 4
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
B5
Failed to transit to Application-
Mode.
U p d a t i n g f a i l B 5
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error dis-
play, press and hold the "Power opera-
tion" button for ve seconds.
---Check the rmware version after updating.---
After updating the rmware, check the version. See "
1. Version Display Mode
" (18 page ).
61

Denon AVR-X1100W Specifications

General

Receiver type	Surround
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
Supported radio bands	AM, FM
Optical drive included	No
Display	VFL
Product color	Black
Audio decoders	Dolby Digital 5.1, Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Plus, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8600 g
