Paths to be conrmed Display Settings What to conrm
8
Analog Amp Assign
(Amp Assign :
ZONE3)
g.08
A08:ASSIGN-Z3
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z3 Source : Source
Amp assign : 7.1ch + ZONE3
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : On
・ Analog input ⇒ Speaker output (Height2 (ZONE3) L/R)
・ Analog input ⇒ Pre OUT output (ZONE3 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
9
Analog Amp Assign
（Amp Assign :
ZONE2/ZONE3-
MONO）
g.09
A09:ASSIGN-Z2/3M
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Z3 Source : Source
Amp assign : 7.1ch + ZONE2/3
Floor Layout : 5ch&SB
MAIN ZONE : On
ZONE2 : On
ZONE3 : On
・ Analog input ⇒ Speaker output (Height2 (ZONE2) L, Height2 (ZONE3) R)
・ Analog input ⇒ Pre OUT output (ZONE2 L/R MONO, ZONE3 L/R MONO)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
10
Amp Assign
(Amp Assign :
BiAMP)
g.10a
g.10b
A11:ASSIGN-BiAMP
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 7.1ch + BiAMP
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・Analog input ⇒ Speaker output (Height2 L/R (Top Front))
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
11 Front Height
g.11a
g.11b
A14:FRONT HEIGHT
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 9.1ch
Floor Layout : 5ch
Height Sp : 4ch
Dolby Sp : None
Height Layout : Top Front & Top Rear
Speaker Select : Floor & Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・Analog input ⇒ Speaker output (Height1 L/R (Top Front), Height2 L/R (Top Front))
・ Analog input ⇒ Pre OUT output (Height1 L/R (Top Front), Height2 L/R (Top Rear))
・ Pre OUT output
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
12
Front Amp ⇒ Sur-
round Back
g.12a
g.12b
A20:F-AMP BACK
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 11.1ch
Height Speakers : 4Height Speakers
Height Layout : Top Front & Top Rear
Pre OUT Channel : Front
Speaker Select : Floor & Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ Analog input ⇒ Speaker output (S.Back L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
