Paths to be conrmed Display Settings What to conrm
13 ZONE2 AD
g.13a
g.13b
A24:Z2 A/D
Input Source : Online Music
Input Mode : Auto
Sound mode : DIRECT
Z2 Source : CBL/SAT
Amp assign : 9.1ch
Floor Layout : 5.1&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : On
ZONE2 : On
ZONE3 : Off
・ Analog input ⇒ Speaker output (Front L/R)
・ Analog input ⇒ Pre OUT output (Front L/R)
(
b
The input source can be switched to any source except Online Music.)
1.6. Conrmation items for the video system
See the block diagram g.XXth.
Paths to be conrmed Display Settings What to conrm
1 Analog Video pass g.14
V01:VIDEO PASS
Input Source : CBL/SAT
MAIN ZONE : On
ZONE2 : On
・ Component input ⇒ Component output
・ CVBS input ⇒ CVBS output
(
b
The input source can be switched to any source except CBL/SAT.)
2
Video Convert
(Analog or HDMI ⇒
HDMI)
g.15a
g.15b
V02:V.CONVERT
Input Source : CBL/SAT
Video Conversion (IP Scaler) : "Auto", All sources
IP Scaler : "HDMI", All sources
Resolution : "Auto", All sources
MAIN ZONE : On
ZONE2 : Off
・ HDMI input ⇒ IP Scaler ⇒ HDMI output.
・ ETHERNET input ⇒ IP Scaler ⇒ HDMI output.
・ CVBS input ⇒ IP Scaler ⇒ HDMI output.
・ Component input ⇒ IP Scaler ⇒ HDMI output.
(
b
The input source can be switched to any source except CBL/SAT.)
3
HDMI pass
(MAIN ZONE)
g.16
V03:HDMI PASS
Input Source : CBL/SAT
Video Conversion (IP Scaler) : Off
MAIN ZONE : On
ZONE2 : Off
・ HDMI input (MAIN function) ⇒ HDMI output (MAIN)
(
b
The input source can be switched to any source except CBL/SAT.)
4
HDMI CEC
(Control Monitor :
HDMI Monitor1)
g.17
V04:HDMI CEC
Input Source : CBL/SAT
HDMI Control : On
MAIN ZONE : On
ZONE2 : Off
・ When the power supply of a TV is put in the standby mode, make sure that the power supply
of this unit is also put in the standby mode.
(
b
The input source can be switched to any source except CBL/SAT.)
・ The ARC path can also be checked (check this using the TV input source).
5
HDMI Audio
(Audio : AVR)
g.18a
g.18b
g.18c
V05:H.AUDIO-AVR
Input Source : CBL/SAT
HDMI Control : Off
HDMI Audio : AVR (if checking the audio output from AVR)
・ HDMI input (PCM, DolbyDigital, DTS) ⇒ Speaker output.
・ HDMI input(HD audio) ⇒ Speaker output.
(
b
The input source can be switched to any source except CBL/SAT.)
6
HDMI Audio
(Audio : TV)
g.19a
g.19b
V06:H.AUDIO-TV
HDMI Audio : TV (if checking the audio output from TV)
・ HDMI input (PCM, DolbyDigital, DTS) ⇒ HDMI output (audio output from connected TV)
(
b
The input source can be switched to any source except CBL/SAT.)
7 GUI g.20
V07:GUI MENU ON
Input Source : CBL/SAT
IP Scaler : On, All sources
Resolution : "AUTO", All sources
Setup Menu : On
MAIN ZONE : On
ZONE2 : Off
・ GUI display ⇒ HDMI output.
(
b
The input source can be switched to any source except CBL/SAT.)
8
HDMI pass
(MAIN ZONE2)
g.21
V08:ZONE2 HDMI
Input Source : CBL/SAT
Z2 Source : Source
MAIN ZONE : On
ZONE2 : On
ZONE3 : Off
・ HDMI input (ZONE2 Function) ⇒ HDMI output (ZONE2)
(
b
The input source can be switched to any source except CBL/SAT.)
145
Caution in
servicing
Electrical Mechanical Repair Information Updating
