Denon AVR-X4300H Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q'ty New Ver
C4374 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C4375 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C4381 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C4382 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C4383 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C4384 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C4396 nsp CAP,ALUMINUM ELECTROLYTIC CAPACITORS(16V/100uF) CCEC1CMVG101T 1
C4404 nsp CAP,ALUMINUM ELECTROLYTIC CAPACITORS(16V/100uF) CCEC1CMVG101T 1
C4406 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C4407 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C4411 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C4412 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C4417 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C4418 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C4420 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C4421 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C4423 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C4424 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C5001 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C5002 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C5003 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1
C5004 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C5005 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C5006 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C5091 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C5092 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CCUS1A105KCS 1
C5093 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CCUS1A105KCS 1
C5094 nsp RES, CHIP(1005/5%/8.2Kohm) CRJ06IJ822T 1
C5098 nsp CAP, CHIP(1005, 25V/0.022uF, X7R)_SAMSUNG CCUI1E223KCS 1
C5101 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C5111 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C5112 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C5113 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C5114 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C5115 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C5116 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C5119 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
OTHER PARTS GROUP
BK101 nsp BRACKET , PCB CMD1A569-V1 1
BK102 nsp BRACKET , PCB CMD1A629 1
BK103 nsp BRACKET , PCB CMD1A569-V1 1
BK106 nsp BRACKET , LEGO VMD1A960 1 *
BK107 nsp BRACKET , LEGO VMD1A960 1 *
BK108 nsp BRACKET , LEGO VMD1A960 1 *
BK109 nsp BRACKET , LEGO VMD1A960 1 *
BN21A nsp PINSOCKET(15P,1.25mm,ANGLE,B-TO-B) CJP15HJ282Z 1
BN23A nsp PIN SOCKET (25P,1.25mm,ANGLE, B-TO-B) CJP25HJ282Z 1
BN24A nsp PIN SOCKET (27P,1.25mm,ANGLE,B-TO-B) CJP27HJ282Z 1
BN25A nsp PIN SOCKET (25P,1.25mm,ANGLE, B-TO-B) CJP25HJ282Z 1
BN26A nsp PINSOCKET(15P,1.25mm,ANGLE,B-TO-B) CJP15HJ282Z 1
BN27A nsp PINSOCKET(15P,1.25mm,ANGLE,B-TO-B) CJP15HJ282Z 1
CN321 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/5PIN CJP05GI288ZY 1
CN431 nsp WAFER, FFC(23PIN, 1mm STRAIGHT) CJP23GA333ZR 1
CN501 nsp PIN HEADER , (DUAL ROW, 80PIN(2X40), 1.27mm PITCH) CJP80GA370ZU 1 *
CN502 nsp PIN HEADER , (DUAL ROW, 42PIN(2X21), 1.27mm PITCH) CJP42GA370ZU 1 *
CN69B nsp WAFER, FFC, SMD(40P-1mm, STRAIGHT) CJP40GA193ZY 1
CN704 nsp WAFER, 2mm, SMD, Vertical, 07p CJP07GA208ZY 1
CN781 nsp WAFER , SMD (2MM PITCH) CJP06GA208ZY 1
CN903 nsp WAFER, STRAIGHT 2.5MM DIP 06P CJP06GA353ZJ 1
JK201 943643101110S JACK, 2P(ORG),SILVER CJJ4N068Y 1
JK202 943262100150S MODULE , OPTICAL(RX 16MHz) CJSJSR1124 1
JK203 943262100150S MODULE , OPTICAL(RX 16MHz) CJSJSR1124 1
JK204 943643101920S JACK , RCA (1P, BK, GOLD PLATE) CJJ4M073ZY 1
JK381 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1
JK382 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1
JK383 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1
JK384 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1
JK391 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1
JK392 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1
JK393 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1
JK394 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1
JK431 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1
JK432 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1
JK501 943643102430S JACK , RJ-45 W/TRANSFORMER CJJ9L029Z 1
L1001 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L1002 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L1003 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1004 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1005 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1006 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1008 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1009 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1010 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1011 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L1012 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L1013 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L1014 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L1015 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L1016 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L1017 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1018 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1019 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1020 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1022 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1023 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1024 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1025 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1029 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1030 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1031 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1032 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1033 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1034 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1111 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1113 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1114 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1115 nsp COIL , SMD 5040, 3.6uH CLQ28E3R6NRH 1
L1121 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1124 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1125 nsp COIL , SMD 5040, 3.6uH CLQ28E3R6NRH 1
L1131 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1134 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1135 nsp COIL , SMD 5040, 3.6uH CLQ28E3R6NRH 1
25

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
