Denon AVR-X4300H Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q'ty New Ver
L1171 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1174 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1175 nsp COIL , SMD(2.2uH, 4.6A 5040, 50X40) CLQ28E2R2NRH 1
L1181 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1184 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1185 nsp COIL , SMD(2.2uH, 4.6A 5040, 50X40) CLQ28E2R2NRH 1
L1191 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1194 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1195 nsp COIL , SMD(2.2uH, 4.6A 5040, 50X40) CLQ28E2R2NRH 1
L1201 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1204 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1205 nsp COIL , SMD(2.2uH, 4.6A 5040, 50X40) CLQ28E2R2NRH 1
L1211 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1214 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1215 nsp COIL , SMD(2.2uH, 4.6A 5040, 50X40) CLQ28E2R2NRH 1
L1221 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L1222 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L1223 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L1224 nsp FERRITE CHIP BEAD(2012/120R)
CLZBLM21AG121SN1
1
L1225 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L2201 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
L3501 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3502 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3503 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3504 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3505 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3506 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3507 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3508 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3509 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3510 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3511 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3512 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3513 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3801 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3802 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3804 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3805 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3806 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3808 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3809 nsp FERRITE CHIP BEAD(30R/2012/3000mA)
CLZBLM21PG300SN1D
1
L3810 nsp FERRITE CHIP BEAD(30R/2012/3000mA)
CLZBLM21PG300SN1D
1
L3901 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3902 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3904 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3905 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3906 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3908 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L3909 943113100000S COMMON MODE FILTER (1210, 90ohm) CLZ9Z188Z 1
L3910 nsp FERRITE CHIP BEAD(30R/2012/3000mA)
CLZBLM21PG300SN1D
1
L3911 nsp FERRITE CHIP BEAD(30R/2012/3000mA)
CLZBLM21PG300SN1D
1
L4001 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4002 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4003 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4004 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4005 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4006 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4007 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4008 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4010 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4012 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4013 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4014 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4015 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4016 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4301 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L4303 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L4304 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L4305 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L4307 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L4308 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
L4309 nsp FERRITE CHIP BEAD(30R/2012/3000mA)
CLZBLM21PG300SN1D
1
L4310 nsp FERRITE CHIP BEAD(30R/2012/3000mA)
CLZBLM21PG300SN1D
1
L4311 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L4312 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L4313 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L4314 943113100000S COMMON MODE FILTER (1210, 90ohm) CLZ9Z188Z 1
L4321 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L4322 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L4323 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L4324 943113100000S COMMON MODE FILTER (1210, 90ohm) CLZ9Z188Z 1
L5091 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T 1
L5111 nsp COMMON MODE FILTER (2012, 90ohm) CLZ9Z174Z 1
L5112 nsp COMMON MODE FILTER (2012, 90ohm) CLZ9Z174Z 1
X1501 943141101260S X-TAL, SMD(12MHz/8pF, FA-238V, 3.2X2.5) COX12000I080SP 1
X2001 943141101310S X-TAL, SMD(24.576MHz/10pF, FA-238, 3.2X2.5) COX24576I100SP 1
X2281 236810011501S OSC , SMD(22.5792MHz, 2.5X2.0, 15P, 1.6V~3.6V) COX22579I150SP 1
X2501 943141101280S X-TAL, SMD(25MHz/12pF, FA-238, 3.2X2.5) COX25000I120SP 1
X2601 943141101280S X-TAL, SMD(25MHz/12pF, FA-238, 3.2X2.5) COX25000I120SP 1
X2701 943141101280S X-TAL, SMD(25MHz/12pF, FA-238, 3.2X2.5) COX25000I120SP 1
X2801 943141101280S X-TAL, SMD(25MHz/12pF, FA-238, 3.2X2.5) COX25000I120SP 1
X3501 943141101300S X-TAL, SMD(27MHz/12pF, FA-238, 3.2X2.5) COX27000I120SP 1
X3801 943141101290S X-TAL, SMD(27MHz/7pF, FA-238, 3.2X2.5) COX27000I070SP 1
X3901 943141101290S X-TAL, SMD(27MHz/7pF, FA-238, 3.2X2.5) COX27000I070SP 1
X4001 943141101300S X-TAL, SMD(27MHz/12pF, FA-238, 3.2X2.5) COX27000I120SP 1
X4301 943141101290S X-TAL, SMD(27MHz/7pF, FA-238, 3.2X2.5) COX27000I070SP 1
26
