Denon AVR-X6200W Service Manual

Pathsconrmationitem Display Settings ContentsofconrmationRemarks
4
Digital (signal) Path
(ZONE3)
A 0 4 : D I G I T A L - Z 3
Input Source : Online Music
Input Mode : Auto
Sound mode : Stereo
Amp assign : 7.1ch + ZONE3
Speaker for ZONE3 : Front Wide/Height2
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : ON
・Digital (PCM) input ⇒ Speaker output (Front Wide/Height2 L/R → ZONE3 L/R)
・Digital (PCM) input ⇒ Preout output (ZONE3 L/R)
(
b
As the input source, you can switch from Online Music to other ones.)
5
HDMI
(MAIN ZONE)
A 0 5 : H D M I
Input Source : CBL/SAT
Input Mode : HDMI (xed)
Sound mode : Stereo
Amp assign : 9.1ch
Floor Layout : 5ch & Surround Back
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・HDMI Input ⇒ Speaker output (Front L/R)
・HDMI Input ⇒ Preout output (Front L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
6
A/D
(MAIN ZONE)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : Multi Ch Stereo
Amp assign : 9.1ch
Floor Layout : 5ch & Surround Back & Front Wide
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Speaker Select : Floor
Speaker Cong : All Speaker = Small/Subwoofer = 2spkrs
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R, Front Wide L/R)
・ Analog input ⇒ Preout output, SW (20Hz) (Front L/R, Center, Subwoofer1/2, Surround L/R, Surround Back L/R, Front Wide L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
7
Amp Assign
(ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Amp assign : 7.1ch + ZONE2
Speaker for ZONE2 : Surround Back
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : ON
ZONE2 : ON
ZONE3 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R → ZONE2 L/R)
・Analog input ⇒ Preout output (ZONE2 L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
8
Amp Assign
(ZONE3)
A 0 8 : A S S I G N - Z 3
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Amp assign : 7.1ch + ZONE3
Speaker for ZONE3 : Front Wide/Height2
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : ON
・Analog input ⇒ Speaker output (Front Wide/Height2 L/R → ZONE3 L/R)
・Analog input ⇒ Preout output (ZONE3 L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
9
Amp Assign
(ZONE2/ZONE3-MONO)
A 0 9 : A S S I G N - Z 3 / 3 M
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Z3 Source : Source
Amp assign : 7.1ch + ZONE2/3
Speaker for ZONE2/3 : Height1
Floor Layout : 5ch & Surround Back & Front Wide
MAIN ZONE : ON
ZONE2 : ON
ZONE3 : ON
・Analog input ⇒ Speaker output (Height1 L → ZONE2 MONO, Height2 R → ZONE3 MONO)
・Analog input ⇒ Preout output (ZONE2 L/R → ZONE2 MONO, ZONE3 L/R → ZONE3 MONO)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
g.04a
g.04b
g.05a
g.05b
g.05c
g.06a
g.06b
g.07
g.08
g.09
27

Denon AVR-X6200W Specifications

General

Display	VFL
Product color	Silver
RS-232 ports	1
12V trigger ports quantity	2
Speakers connectivity type	RCA
HDMI in	8
Composite video in	5
Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	13.2
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
Number of HDMI outputs	3
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
3D	-
Supported graphics resolutions	4096 x 2160
Card reader integrated	No
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV
Image formats supported	JPG

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	167 mm
Weight	14100 g
