Denon AVR-X6200W Service Manual

Pathsconrmationitem Display Settings ContentsofconrmationRemarks
10
Amp Assign
(7.1ch (Bi-Amp)
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Amp assign : 7.1ch + Bi-Amp
Speaker for Bi-Amp : Surround Back
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R → Front L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
11
Front Height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Amp assign : 11.1ch
Floor Layout : 5ch & Surround Back
Height Sp : 4ch
Dolby Sp : None
Height Layout : Top Front & Top Rear
Pre-out Channel = Top Rear
Speaker Select = Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Height 1 L/R → Top Front L/R)
・Analog input ⇒ Preout output (Height 1 L/R → Top Front, Height 2 L/R → Top Rear)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
12
Front Wide
A 1 5 : F R O N T W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Vol. : 60.0 (-20.0dB)
Amp assign : 11.1ch
Floor Layout : 5ch & Front Wide
Height Sp : 4ch
Dolby Sp : None
Height Layout : Front Height & Top Middle
Pre-out channel : Top Middle
Speaker Select = Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front Wide L/R)
・Analog input ⇒ Preout output (Front Wide L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
13
Front Amp>>Height 1
A 2 0 : F - A M P H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi ch Stereo
Amp assign : 11.1ch
Height Speakers = 4Height Speakers
Height Layout = Top Front & Top Rear
Pre-out Channel = Front & Top Rear
Speaker Conog > Surround Back = None
Speaker Select = Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Height1 L/R → Top Front L/R)
・Analog input ⇒ Preout output (Height1 L/R → Top Front, Height2 → Top Rear L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
14
Front Amp>>Front Wide
A 2 1 : F - A M P W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi ch Stereo
Amp assign : 11.1ch
Floor Layout : 5ch & Surround Back & Front Wide
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Pre-out Channel : Front
Speaker Select : Front
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front Wide L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
g.10a
g.10b
g.11a
g.11b
g.12a
g.12b
g.13a
g.13b
g.14a
g.14b
28

Denon AVR-X6200W Specifications

General

Display	VFL
Product color	Silver
RS-232 ports	1
12V trigger ports quantity	2
Speakers connectivity type	RCA
HDMI in	8
Composite video in	5
Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	13.2
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
Number of HDMI outputs	3
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
3D	-
Supported graphics resolutions	4096 x 2160
Card reader integrated	No
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV
Image formats supported	JPG

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	167 mm
Weight	14100 g
