Denon RCD-N7 Service Manual

100
Ref. No. Part No. Part Name Remarks Q'ty New
D240 nsp DIODE , ZENER HVDMTZJ16BT
D241 nsp DIODE , ZENER HVDMTZJ20BT
D251-255 00MHZ21303210 DIODE , CHIP HVD1SS355T
D262,263 00MHZ21303210 DIODE , CHIP HVD1SS355T
D302 00D2760794900 DIODE , CHIP CVDKDS160RTKP
D401 00D2760794900 DIODE , CHIP CVDKDS160RTKP
D501-504 00MHZ21303210 DIODE , CHIP HVD1SS355T
D605-606 00MHZ21303210 DIODE , CHIP HVD1SS355T
D607,608 00D2760794900 DIODE , CHIP CVDKDS160RTKP
D609 00MHZ21303210 DIODE , CHIP HVD1SS355T
D612,613 00D2760794900 DIODE , CHIP CVDKDS160RTKP
D615,616 00D2760794900 DIODE , CHIP CVDKDS160RTKP
CAPACITORS GROUP
C131 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C143 nsp CAP , ELECT CCEA1CKS101T
C144 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C145 nsp CAP , ELECT CCEA1CKS101T
C146 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C174 nsp CAP , ELECT CCEA1CKS101T
C175 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C176 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C177 nsp CAP , ELECT CCEA1CKS101T
C178 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C180 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C185 nsp CAP , ELECT CCEA1CKS101T
C186 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C187 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C188 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C189 nsp CAP , ELECT CCEA1CKS101T
C190 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C191 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C201 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C202 nsp CAP , CHIP (1608, 50V/2200pF)
CCUS1H222KC
C203 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C204 nsp CAP , CHIP (1608, 50V/4700pF) CCUS1H472KC
C205 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C206 nsp CAP , CHIP (1608, 50V/0.015uF) CCUS1H153KC
C207 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C209 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C210 nsp CAP , CHIP ELECT HCEC0JRV102T
C211 nsp CAP , CHIP (1608, 50V/0.033uF) CCUS1H333KC
C212 nsp CAP , CHIP (1608, 50V/5600pF) CCUS1H562KC
C213 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C214,215 nsp CAP , CHIP (1608, 50V/470pF) CCUS1H471JA
C216 nsp CAP , CHIP ELECT HCEC0JRV102T
C217 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C219,220 nsp CAP , CHIP (1608, 50V/0.047uF) CCUS1H473KC
C221 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C224 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C225 nsp CAP , CHIP (1608, 50V/15pF) CCUS1H150JA
C226 nsp CAP , CHIP (1608, 50V/18pF) CCUS1H180JA
C227 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C228 nsp CAP , ELECT CCEA1AKS101T
C229-231 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C232 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C233 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C234,235 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C237 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C238 nsp CAP , CHIP (1608, 50V/0.015uF) CCUS1H153KC
C239 nsp CAP , ELECT CCEA1AKS101T
C240 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C241 nsp CAP , CHIP (1608, 50V/47pF) CCUS1H470JA
C242 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C243 nsp CAP , ELECT CCEA1AKS470T
C244 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
