Denon RCD-N7 Service Manual

51
AK4683 TAS5508
TUNER AUDIO CODEC
PWM CONTROLLER
TAS5142DKD
PACK DIGITAL AMP SP L OUT
CD UNIT
DSP
TAS5142DKD
DIGITAL AMP SP R OUT
TC94A92FG
USB
DM870
Portable In
MUTE PHONES
AUX(1,2)
MUTE SUBWOOFER OUT
MUTE AUX OUT
S
P OUT
+20dB I
m
pe
da
n
c
e 4 ohm
16.12V (18.1dB)
+10dB
VOL MAX : +10dB(6V)
: Analog Input
0dB(2V) : Digital Input
S
W
OUT 1.2V(-4.
2
dB
)
-10dB
AUX/TUNER/MX PORT
HP OUT 770mV(-
9
.2dB)
-20dB
AUX 200mV / TUNER 200mV -6dB(100mV) +6dB(200mV)
CD/USB 200mV
AUX
O
U
T 2
00mV(-2
0
dB
)
-26dB
M-X PORT 100mV
Portable In 120mV TC94A92FG
-26dB(100mV)
-30dB
-6dB
Portablel, CD,USB
0dB(100mV)
-40dB
LEVEL DIAGRAM

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
