Denon RCD-N7 - SMPS PCB ASSY

108
SMPS PCB ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC90 90M-HC300960R I.C , REGULATOR(TO220IS-4) CVIKIA78D33PI
IC91 943235003220S IC, CooLSET ICE3B0365J CVIICE3B0365J
IC92 943235003200S IC , COOLSET CVIICE2B265
IC93 943235003210S I.C , PWM CONTROLLER(PG-DIP-8) CVIICE2QS01
IC94 00MHC3891899F I.C , VOL REGULATOR(18V, TO-220IS) CVIKIA7818API
IC95,96 90M-HC300770R I.C , REGULATOR HVIKIA431BAT
IC97 00MHC3891299F I.C , REGULATOR HVIKIA7812API
IC98 00D2631099022 I.C , REGULATOR HVIKIA7912PI
IC99 90M-HC300770R I.C , REGULATOR HVIKIA431BAT
D901,902 90M-HD201860R DIODE , SCHOTTKY HVDUF4004T
D903 90M-HD201870R DIODE , SCHOTTKY HVDUF4007T
D904 90M-HD201860R DIODE , SCHOTTKY HVDUF4004T
D905 90M-HD201870R DIODE , SCHOTTKY HVDUF4007T
D906,907 90M-HD201860R DIODE , SCHOTTKY HVDUF4004T
D908 90M-HD201870R DIODE , SCHOTTKY HVDUF4007T
D909,910 943203003150S DIODE HVD1N4007T
D911 nsp DIODE , FAST SWITCHING(0.5W, SOD-123) CVD1N4448W
D912 nsp DIODE , ZENER HVDMTZJ20BT
D913 nsp DIODE , ZENER HVDMTZJ16BT
D914,915 nsp DIODE , ZENER HVDMTZJ20BT
D916 nsp DIODE , ZENER HVDMTZJ24BT
D917 nsp DIODE , FAST SWITCHING(0.5W, SOD-123) CVD1N4448W
D918 90M-HD201890R DIODE , ULTRA FAST (DELTA) HVDUF5404H
D919 nsp DIODE , ZENER(27V/0.5W, SOD-123) CVDMM1Z27
D921 nsp DIODE , ZENER(20V/0.5W, SOD-123) CVDMM1Z20
D922 943203003150S DIODE HVD1N4007T
D923,924 nsp DIODE , FAST SWITCHING(0.5W, SOD-123) CVD1N4448W
D927-929 nsp DIODE , FAST SWITCHING(0.5W, SOD-123) CVD1N4448W
D931 90M-HD201990R DIODE HVD31DQ06H
D933 90M-HD201860R DIODE , SCHOTTKY HVDUF4004T
D934 nsp DIODE , ZENER(27V/0.5W, SOD-123) CVDMM1Z27
D935 nsp DIODE , ZENER
HVDMTZJ16BT
D942 943204003160S DIODE , SCHOTTKY (100V/3A) HVD31DQ10FC5
D943 90M-HD201890R DIODE , ULTRA FAST (DELTA) HVDUF5404H
D944,945 90M-HD201860R DIODE , SCHOTTKY HVDUF4004T
D946 90M-HD201890R DIODE , ULTRA FAST (DELTA) HVDUF5404H
D951 943203003140S DIODE , SCHOTTKY(20A, 200V) CVDFCH20A20
Q901,902 90M-HT600060R T.R HVTKSA708YT
Q903 943235003230S I.C CVISPP11N60C3
Q925 90M-HT800050R T.R HVTKTC3198YT
Q932 90M-BA001460R T.R , TO-92M HVTKRC107MT
Q934 00D2710323907 T.R HVTKTA1273YT
Q936 00MBA20001000 T.R , TO-92M HVTKRC102MT
Q937 00MBA10001000 T.R , TO-92M HVTKRA102MT
CAPACITORS GROUP
C901 nsp CAP , ELECT(TDA, 450V/270UF, 105C, 35X30) CCET450VTDA271N *
C902 943134010940S CAP, ELECT(22uF/100V, 6X11) CCEA2AH220TS
C903 00MDK96472300 CAP , CHIP CCUC1H472KC
C904 943132003090S CAP , CHIP CCUC1H474KC
C905 nsp CAP , CERAMIC CCKT3A222KBL
C906 90M-OA000320R CAP , ELECT CCEA1HH220TS
C907 943134010940S CAP, ELECT(22uF/100V, 6X11) CCEA2AH220TS
C908 00MDK96472300 CAP , CHIP CCUC1H472KC
C909 943132003090S CAP , CHIP CCUC1H474KC
C910 nsp CAP , CERAMIC CCKT3A222KBL
C911 943134003060S CAP , ELECT(KRH, 450V/22UF, 12.5X25)
CCET450VKRH220KS
C912 00MDK56222300 CAP , CHIP(2012, 2200PF/50V) CCUC1H222KC
C913 00MDD95101300 CAP , CHIP CCUC1H101JA
C914 nsp CAP , CERAMIC CCKT3A471KBL
C915 943134010940S CAP, ELECT(22uF/100V, 6X11) CCEA2AH220TS
