Denon RCD-N7 Service Manual

97
PARTS LIST OF P.C.B. UNIT
zParts for which "nsp" is indicated on this table cannot be supplied.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
DISPLAY PCB ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC81 8R2431005500S MCU, IC (R32C/100, 144P6Q-A)
IC83 943231011200S 2A Low Drop Regulator (HRP-5) CVIBA00DD0WHFP
Q932 90M-HX800010R T.R , CHIP , SOT-23 HVTKRC102S
Q933 90M-HX600010R T.R , CHIP , SOT-23 HVTKRA102S
Q934 90M-HX800010R T.R , CHIP , SOT-23 HVTKRC102S
Q935 90M-HX600010R T.R , CHIP , SOT-23 HVTKRA102S
Q936 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ
Q937 90M-HX800010R T.R , CHIP , SOT-23 HVTKRC102S
D903 00D2760794900 DIODE , CHIP CVDKDS160RTKP
D933,934 00D2760794900 DIODE , CHIP CVDKDS160RTKP
D941 nsp DIODE , ZENER(CHIP,2.7V) HVDUDZS2.7BSR
D944,945 00D2760794900 DIODE , CHIP CVDKDS160RTKP
D946 90M-HI101090R L.E.D , 2COLOR(RED/GREEN) HVDSPR39MVW3
CAPACITORS GROUP
C801 nsp CAP, CHIP (4.7uF/6.3V, 1608, MURATA GRM18) CCUS0J475KC
C802 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C805 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C806 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C808,809 nsp CAP , CHIP (1608, 10V/4.7uF) CCUS1A475KC
C810-815 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C816 nsp CAP , CHIP (1608, 50V/33pF) CCUS1H330JA
C817 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C818 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C819 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C823 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C824 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C825 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C826 nsp CAP , CHIP (1608, 50V/33pF) CCUS1H330JA
C827 nsp CAP, CHIP 1UF/25V/2012/Y5V CCUC1E105ZF
C828,829 nsp CAP , CHIP (1608, 10V/1uF) CCUS1A105KC
C830 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C831,832 nsp CAP , CHIP (25V/4.7uF, 2125 SIZE) CCUC1E475KC
C833 nsp CAP , ELECT
CCEA1HKS100T
C834 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C835 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C836,837 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C838 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C839 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C840 nsp CAP , ELECT CCEA1VKS470T
C841 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C842 nsp CAP , ELECT ( 47uF/50V ) CCEA1HKS470T
C843 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C844 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C845 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C847 nsp CAP, CHIP (1uF/25V, 2012, MURATA GRM21) CCUMUC1H105KC
C850-855 nsp RES , CHIP(0 OHM , 5% , 1608) CRJ10DJ0R0T
C856 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C857,858 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C859 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C860 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C861 nsp CAP , CHIP ELECT HCEC1CRV2100T
C869 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C870 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C871 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C931 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C932 nsp CAP , ELECT CCEA1CKS470T
NOTE :
When update Firmware, please
conrm a last version in SDI.
Use the service board after
updating it.

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
