Denon RCD-N7 Service Manual

99
MAIN PCB ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC11 8R2431005400S MCU, IC (R32C/100, 144P6Q-A) CVIR5F64169DFD
IC12 943231011000S I,C , REGULATOR(3.3V SMD Type) BVIBA33BC0FP
IC13 943231011210S I.C , REGULATOR
(SWITCH LOW DROP,5V,DPAK-5)
CVIKIA78R050F
IC18 90M-HC900160R I.C , REGULATOR(SOT-223) CVIKIA1117S15
IC21 943245006980S I.C , CD DSP (SERVO,AMPLIFIER,DSP,LQFP-80P) CVITC94A92FG
IC22 943249011290S I.C EEPROM(256K, 32-kword x 8 bit)
CVIR1EX24256ASAS0A
IC25 943239011300S Reset IC (3V, SSOP5) CVIBD4730G
IC26 943231011220S I.C , REGULATOR (9V, DPAK-5) CVIKIA78R09F
IC31 943239006900S I.C , 5-CH MOTOR DRIVE IC
(WITH REG,SSOP-28P)
CVIIP4001CRLTF
IC32 943231011210S I.C , REGULATOR
(SWITCH LOW DROP,5V,DPAK-5)
CVIKIA78R050F
IC41 00D2623762008 I.C , AUDIO CODEC(64PIN_LQFP, 0.5MM) CVIAK4683EQ
IC42,43 00MHC008005K0 I.C , INVERTER(CMOS) CVITC7WHU04FU
IC44 00MHC10102090 I.C , OP AMP (JRC) HVINJM2068MDTE1
IC51 00MHC12273370 I.C , PWM PROCESSOR CVITAS5508BPAG
IC52 00MHC10102090 I.C , OP AMP (JRC) HVINJM2068MDTE1
IC53 00MHC10200090 I.C , HEADPHONE (JRC) HVINJM4556AL
IC71,72 00D2623503911 I.C , STEREO DIGITAL AMP CVITAS5142DKDG4
Q201 90M-HX600020R T.R , CHIP HVTKTA1504SYRTK
Q235,236 90M-HX800010R T.R , CHIP , SOT-23 HVTKRC102S
Q237 90M-BA001600R T.R , CHIP , SOT-23 HVTKRA107S
Q238 90M-HX800080R T.R , CHIP , SOT-23 HVTKRC107S
Q239 90M-HX800010R T.R , CHIP , SOT-23 HVTKRC102S
Q251,252 90M-HX800010R T.R , CHIP , SOT-23 HVTKRC102S
Q256 90M-HX800010R T.R , CHIP , SOT-23 HVTKRC102S
Q301 90M-HX800100R T.R , CHIP HVTKTC3875SYRTK
Q303 90M-HX800010R T.R , CHIP , SOT-23 HVTKRC102S
Q404-407 90M-HT300970R T.R , CHIP HVTKTC2875B
Q501 90M-HX800080R T.R , CHIP , SOT-23 HVTKRC107S
Q502 90M-BA001600R T.R , CHIP , SOT-23 HVTKRA107S
Q503 90M-HX800080R T.R , CHIP , SOT-23 HVTKRC107S
Q504 90M-BA001600R T.R , CHIP , SOT-23 HVTKRA107S
Q608,609 90M-HT800110R T.R , CHIP HVTKTC4075GR
Q610-615 90M-HT300970R T.R , CHIP HVTKTC2875B
Q616 90M-HX800010R T.R , CHIP , SOT-23 HVTKRC102S
Q617 90M-HX600010R T.R , CHIP , SOT-23 HVTKRA102S
Q618 90M-HX800010R T.R , CHIP , SOT-23 HVTKRC102S
Q622 90M-HX800010R T.R , CHIP , SOT-23 HVTKRC102S
Q623 90M-HX600010R T.R , CHIP , SOT-23 HVTKRA102S
Q624 90M-HX800010R T.R , CHIP , SOT-23 HVTKRC102S
Q701 90M-HX800080R T.R , CHIP , SOT-23 HVTKRC107S
Q702 90M-BA001600R T.R , CHIP , SOT-23 HVTKRA107S
Q705 90M-HX600020R T.R , CHIP HVTKTA1504SYRTK
Q706 90M-HX800100R T.R , CHIP HVTKTC3875SYRTK
Q707 90M-HX600020R T.R , CHIP HVTKTA1504SYRTK
Q708 90M-HX800100R T.R , CHIP HVTKTC3875SYRTK
Q751 90M-HX800080R T.R , CHIP , SOT-23 HVTKRC107S
Q752 90M-BA001600R T.R , CHIP , SOT-23 HVTKRA107S
D103 00D2760794900 DIODE , CHIP CVDKDS160RTKP
D201 00MHZ21303210 DIODE , CHIP HVD1SS355T
D202,203 00D2760794900 DIODE , CHIP CVDKDS160RTKP
D207 nsp DIODE , RECT CVD1N4003T
D208-211 00MHZ21303210 DIODE , CHIP HVD1SS355T
D230 nsp DIODE , ZENER HVDMTZJ16BT
D231 nsp DIODE , ZENER HVDMTZJ11BT
D232 nsp DIODE , ZENER HVDMTZJ20BT
D233 nsp DIODE , ZENER HVDMTZJ5.6BT
D234 nsp DIODE , ZENER HVDMTZJ7.5BT
D235 nsp DIODE , ZENER HVDMTZJ20BT
D238,239 00D2760794900 DIODE , CHIP CVDKDS160RTKP
NOTE :
When update Firmware, please
conrm a last version in SDI.
Use the service board after
updating it.

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
