Denon RCD-N7 Service Manual

98
Ref. No. Part No. Part Name Remarks Q'ty New
C933,934 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C941 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C944 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C946 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C949 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C950,951 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C952,953 nsp CAP , CHIP (1608, 50V/180pF) CCUS1H181JA
C955,956 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C957 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C958 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C959 nsp CAP , ELECT CCEA1AKS221T
C964 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C965 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C966 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C967 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C968,969 nsp CAP , CHIP (1608, 50V/2700pF) CCUS1H272KC
C970 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C971 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C972 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C973 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C974 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C975 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C976 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C977 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C978,979 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C980 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C982 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C983 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C985 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C988,989 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C991 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C992,993 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C994 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C995 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C996 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
OTHER PATRS GROUP
BK81-84 nsp BRACKET , PCB CMD1A569
BN81 nsp WIRE ASS'Y (SHIELD, 7P, 2MM, 250MM)
CWB1C90725047001
BN82 nsp WIRE ASS'Y (SHIELD, 5P, 2MM, 250MM) CWB1C905250NG002
BN83 nsp WIRE ASS'Y (SHIELD, 6P, 2MM, 120MM) CWB1C906120NG001
CN84 nsp WAFER, SMD (30P, 0.5mm, FRONT FLIP) CJP30GB278ZY
CN88 nsp WAFER, STRSIGHT, 1MM, SMD CJP30GA193ZY
JK81 943643001320S JACK , USB STRAIGHT(BLACK) CJJ9X006Z
JK82 nsp JACK , IPOD CONNECTOR (37P, DENON)
CJJ00D051451004-DM
JK83,84 00D9430105204 JACK , HEADPHONE (SILVER) HJJ2D003Y
L801,802 nsp BEAD , FERRITE (FCM2012KF-121T08 , 120
OHM)
CLZ9R010Z
L904-907 nsp CHIP , BEAD HLZ9Z014Z
L931 nsp FERRITE , CHIP BEAD(220ohm, 2012) CLZ9R006Z
L932,933 nsp RES , CHIP , 0 OHM, 5% , 1/8W , 2012 CRJ18AJ0R0T
RC81 00D9430194706 SENSOR , REMOCON CRVKSM603TH5B
S901-904 90M-SP001210R SW , TACT CST1A012ZT
S906-909 90M-SP001210R SW , TACT CST1A012ZT
S911,912 90M-SP001210R SW , TACT CST1A012ZT
X802 943142011280S 16M Resonator
COXCSTCE16M0V51
943606011480S CABLE , CARD(1.0MM, 30P, 180MM, B TYPE) CN88 CWC4F4A30A180B08

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
