Denon RCD-N7 Service Manual

106
ETHER NET PCB ASS'Y
d
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC21 236710076509S
I.C , IPOD AUTHENTICATION CHIP FROM
MARANTZ
CVI236710076509S-DM
IC22 943236011750S USB 2.0 De/MultiPlexer Switch (480Mbps, 1:2)_ CVITS3USB30EDGSR *
IC23,24 231810051504S I.C , DC-DC CONVERTER (1A,QFN-20P) CVIEN5311QI
IC28 231810041507S IC , DCDC Converter (3.5A, SOP8) SANKEN CVISI8005QTL
D201,202 90M-HD201840R DIODE , RECTIFIER HVD1SR159-200
D203,204 nsp DIODE , CHIP CVDKDS160RTKP
D210 nsp DIODE , SCHOTTKY (40V,3A, DO-214AC) DELTA CVDSS34SR
D211 nsp DIODE , ZENER (CHIP,5.6V) HVDUDZS5.6BSR
D212 nsp DIODE , ZENER (CHIP,7.5V) HVDUDZS7.5BSR
D213-216 nsp ESD SUPPRESSOR
(ASQS 12U 02 0R2, 0.2pF/12V 1005)
CLZ9Z120Z
D271 nsp DIODE , ZENER (CHIP,5.1V) HVDUDZS5.1BSR
Q201-205 nsp T.R , CHIP , SOT-23 HVTKRC102S
Q206 nsp T.R , CHIP , SOT-23 HVTKRA102S
Q207 nsp T.R , CHIP , SOT-23 HVTKRC102S
Q208,209 nsp T.R , CHIP , SOT-23 HVTKRC104S
CAPACITORS GROUP
C203 nsp CAP , CHIP ELECT HCEC0JRV2220T
C206 nsp CAP , CHIP ELECT(100UF/25V) CCEC1ERV2101T
C208 nsp CAP , CHIP ELECT (100UF/16V) HCEC1CRV2101T
C209-211 nsp CAP , ELEC SMD (150uF/25V, 8X10.5, SANYO) CCEC1EHVH151TY
C214 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C215 nsp CAP , CHIP(2012 SIZE) CCUC1A475ZF
C220 nsp CAP , CHIP (1005, 16V/0.1uF) CCUI1C104KC
C224 nsp CAP , CHIP (1608, 10V/1uF) CCUS1A105KC
C225 nsp CAP, CHIP (4.7uF/25V, 2012, MURATA GRM21) CCUMUC1E475KC
C226-231 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C233-235 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C236 nsp CAP, CHIP (4.7uF/25V, 2012, MURATA GRM21) CCUMUC1E475KC
C237-239 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C240 nsp CAP , CHIP (1608, 10V/1uF) CCUS1A105KC
C241 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C245-255 nsp CAP , CHIP (1608, 50V/0.01uF)
CCUS1H103KC
C257,258 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C259 nsp CAP, CHIP (4.7uF/25V, 2012, MURATA GRM21) CCUMUC1E475KC
C260 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C264,265 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C268 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C270,271 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C273-275 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C279,280 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C282-286 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C288 nsp CAP , CHIP (1608, 50V/180pF) CCUS1H181JA
C290,291 nsp CAP , CHIP ELECT(220UF/6.3V) HCEC0JRV2221T
C294 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C295 nsp CAP , CHIP ELECT HCEC1CRV2220T
C298,299 nsp CAP , CHIP (1608, 10V/4.7uF) CCUS1A475KC
C502 nsp CAP, CHIP (4.7uF/25V, 2012, MURATA GRM21) CCUMUC1E475KC
C503 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C504,505 nsp CAP, CHIP (4.7uF/25V, 2012, MURATA GRM21) CCUMUC1E475KC
C506 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
OTHER PATRS GROUP
BK81,82 nsp BRACKET , PCB CMD1A569
CN21 nsp WAFER , SMD (2MM PITCH) CJP05GA208ZY
CN22 nsp WAFER , SMD (2MM PITCH) CJP06GA208ZY
CN23 nsp WAFER , CARD CABLE SMD CJP07GA193ZY

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
