Denon RCD-N7 Service Manual

107
Ref. No. Part No. Part Name Remarks Q'ty New
CN25 nsp WAFER, 2mm, SMD, Vertical, 8P CJP08GA208ZY
CN26 nsp WAFER , CARD CABLE (SMD, 1MM) CJP23GA193ZY
CN27 nsp 120p connector(SMD) CJP120GA277ZP
F201,202 943661006910S POLY SWITCH (1.6A, 8V) CBA5H1600PSUYT
JK21 00D2051333009 RJ45 with LED CJJ9L019Z
L201 nsp
BEAD , FERRITE
(FCM2012KF-121T08 , 120 OHM)
CLZ9R10Z
L202 nsp FERRITE , CHIP BEAD(220ohm, 2012) CLZ9R06Z
L203 nsp COIL , SMD POWER (22UH/3A) CLQ13E220MRZ
L204 nsp
BEAD , FERRITE
(FCM2012KF-121T08 , 120 OHM)
CLZ9R10Z

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
